ASTM A312 316L stainless steel tubing has many advantages and can be used in a wide variety of fields and applications. It is necessary to comply with the relevant requirements when using to ensure the quality and performance of the pipeline.

Send Inquiry

Product Introduction

ASTM A312 316L is a standard specification stainless steel tube with many advantages, some of which are as follows:

1. Good corrosion resistance: ASTM A312 316L stainless steel pipe has excellent corrosion resistance and can be used in harsh environments such as high temperature, high pressure, acid, alkaline and salt water.

2. High strength and durability: Due to its high strength and durability, ASTM A312 316L stainless steel tubing can be used for a long time without frequent replacement or maintenance.

3. Excellent processability: ASTM A312 316L stainless steel pipe is easy to process and form, and can be easily used by various processing methods, such as cutting, bending, welding, etc., to achieve the desired shape and size.

When using ASTM A312 316L stainless steel pipes, there are a number of requirements that need to be followed to ensure the quality and reliability of the pipes. These requirements include:

1. Ensure the correct installation and joint quality of the pipeline: use professional tools and technology for installation, and ensure the quality and reliability of the pipeline connection points.

2. Regular maintenance and inspection: Regularly check the status and cleanliness of the pipeline, and carry out necessary maintenance to ensure the long-term operation and performance of the pipeline.

3. Comply with relevant standards and safety specifications: When using ASTM A312 316L stainless steel pipes, it is necessary to comply with relevant standards and safety specifications to ensure the safety of personnel and the environment.

tp316 stainless steel

Specification of Stainless Steel 316l Tube

Standard Specifiaction	316L Stainless Steel Tube
Processing	Polishing, Polished Grit 120 to 600, Cut-to-length
ERW Tube Sizes	1/2 upto 24 inch Nominal Bore
Wall Thickness (WT)	Schedule 5S to XXS
Materials Testing	CRYO SERVICE, H2 SERVICE, OXYGEN SERVICE, NACE MR0175
Seamless Tube Sizes	1/2 upto 8 inch Nominal Bore
End	Plain End, Beveled End, Treaded
Length	Single Random, Double Random, Cut Length
EFW Tube Sizes	6 upto 100 inch Nominal Bore

SS 316L Welded Tube Chemical Composition

Looking for 316L Stainless Steel Tubing and SS 316L Schedule 40 Tube material for High temperature applications? AISI 316L Tubing available in 3/4"-24" size range

Grade		Carbon	Sulfur	Manganese	Phosphorus	Nickel	Silicon	Molybdenum	Chromium
316L	Minimum					10.0		2.0-3.0	16.0
316L	Maximum	0.035	0.030	2.0	0.045	14.0	0.75	2.0-3.0	18.0

Mechanical Properties of 316L Schedule 40 stainless steel Tube

Grade	Tensile Properties (MPa) min	Elongational	Yield Properties 0.2% Proof (MPa) min	Hardness
				Brinell (HB) max	Rockwell B (HR B) max
316L	485	40	170	217	95

AISI 316L Schedule 10 Tube Equivalent

Standards	WERKSTOFF NR.	Japanese Industrial Standards	AFNOR	Unified Numbering System	GOST	British Standards	European Standards
SS 316L	1.4404 / 1.4435	SUS 316L	Z3CND17‐11‐02 / Z3CND18‐14‐03	S31603	03Ch17N14M3 / 03Ch17N14M2	316S11 / 316S13	X2CrNiMo17-12-2 / X2CrNiMo18-14-3

UNS S31603 Seamless Tubing Physical Properties

Grade	Density	Modulus (GPa)	Electrical Resistivity (n.m)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)
				0-3150C	0-1000C	0-5380C	at 5000C	at 1000C
316L	8000	193	740	16.2	15.9	17.5	21.5	16.3	500
