Steel Round Bar S20C
Steel round bar S20C is a type of carbon steel round bar that is popularly used in many applications. It has a low carbon content of 0.18-0.23% and medium tensile strength of 570-700 MPa. This type of steel bar is often utilized in manufacturing machinery parts, automotive parts, and construction materials. S20C steel round bar has good machinability and weldability, making it a reliable choice for various mechanical applications. Additionally, it is also cost-effective and readily available in the market.
Product Description of Round Bars Carbon Steel SAE1020 AISI1020 S20C C22
1. Steel grade: SAE1020, 20#, C22, S20C
2. Length: 6M-12M
3. Diameter: 16mm-300mm
4. Product range: round bar, flat bar, square bar
5. Technique: Hot rolled, forged, cold drawn
Specification of Round Bars Carbon Steel SAE1020 AISI1020 S20C C22 S20
|
Material |
SAE 1020 |
Round bar |
Dia(mm) |
16-300mm |
|
Process |
EAF + LF + VD + Forged + Heat Treatment (optional) |
Length (mm) |
Max 12m |
|
|
Heat treatment |
Normalized / Annealed / Quenched / tempered |
Flat bar |
Thickness(mm) |
8-500mm |
|
Delivery condition |
Hot forged +Rough machined (black surface after Q/T)+ Turned (optional) |
Width(mm) |
70-200mm |
|
|
Test |
Ultrasonic test according to SEP 1921-84 D/d |
Length (mm) |
Max 12m |
Chemical Composition of Round Bars Carbon Steel SAE1020 AISI1020 S20C C22
|
C |
Si |
Mn |
Cr |
Ni |
Cu |
|
0.17~0.23 |
0.17~0.37 |
0.35~0.65 |
≤0.25 |
≤0.30 |
≤0.25 |
Packing and Delivery:
Usage and Applications of Round Bars Carbon Steel SAE1020 AISI1020 S20C C22
1. Manufacturing and construction: Rused in the manufacturing and construction industries. They are used to make components, machinery, and structural parts such as beams, columns, and bridges.
2. Infrastructure: These round bars are also used in infrastructure projects such as the construction of oil pipelines, gas pipelines, and water pipes. Their durability and strength make them an ideal choice for such applications.
3. Automotive: used in the automotive industry. They are used to make parts such as axles, crankshafts, and gears. These parts require the strength and toughness that carbon steel provides.
4. Aerospace: The aerospace industry also uses Round Bars Carbon Steel 20C in the manufacture of aircraft components. These bars provide the strength and durability that aircraft structural parts require.
5. Machining: These round bars are also popular in machining applications. They can be easily machined into various shapes and sizes, which makes them a versatile material choice.
6. Agriculture: used in the agriculture sector. They are used to make components such as plows, cultivators, and tillers.
7. Medical Industry: In the medical industry, carbon steel round bars are used to make surgical devices due to their high strength, toughness, and corrosion resistance.
