S960QL High Strength Steel Sheet tempered high strength board process analysis:
Hot metal pretreatment → top and bottom reblowing →LF furnace →RH vacuum treatment → Continuous casting → billet inspection → billet heating → high pressure water descaling → roughing → finishing →ACC water cooling → Straightening → cold bed cooling → finishing → shot blasting → tempering treatment → Performance testing → finished product storage. LF, Si-Ca-Ba wire and RH vacuum treatment are used to ensure the cleanliness of the steel.

Send Inquiry

Product Introduction

High strength steel

960 belongs to the tempered steel plate for high strength structure, and the steel plate is delivered in the tempered (tempering + normalizing) state. The yield strength of 690 is above 960MPa, the general thickness is not greater than 50mm, and most of the thickness is less than 30mm, so it is widely used in the manufacture of more than 100 tons of mining car floor, pumping machinery, excavators, car cranes, crawler cranes, coal mine hydraulic supports, etc.

Q960 tempered steel excellent processing performance: steel plate can be cold processing, bending processing and cutting processing gas cut, even if not preheated will not occur cracks. When preheating, tempered steel should be processed below the tempering temperature. Excellent wear and corrosion resistance: Due to the inclusion of copper, chromium and other alloying elements, compared with general steel, corrosion resistance is good, hardness is relatively high, wear resistance is also good.

high strength steel sheet s960ql1 Chemical composition %

Material	Quality	C	Mn	Si	P	S
S960QL/S960QL1/S960QL2 HSLA steel plate	/	≤0.20	≤1.70	≤0.80	≤0.025	≤0.015
	L				≤0.020	≤0.010
	L1				≤0.020	≤0.010

high strength S960QL structural steel Mechanical properties in table

Material	Yield strength σ0.2 MPa		Tensible strength σb MPa		Elongationδ5 %	V Impact Lengthways
	≥6- 50	＞50-100	≥6 -50	＞50-100
S960QL	≥980	≥970	980-1100		≥13	-20℃ ≥25J
S890QL1						-40℃ ≥26J
S890QL2						-60℃ ≥26J
