304 Premier Stainless Tube
304 Premier Stainless Tube
Stainless steel pipe is a kind of hollow long round steel,Mainly widely used in petroleum, chemical, medical, food,Light industry,mechanical instrumentation and other industrial conveying pipes and machines,Mechanical structural components, etc. Also commonly used as furniture kitchenware.
PRODUCT ADVANTAGES
01 Smooth and flat surface：Strict selection of raw materials, high preci-sion, uniform thickness, smooth surface,high cost performance.
02 High-quality:With international experience and profession-alism, we can provide customers with various high-quality steel products.
03 Corrosion resistance:Stainless steel Pipe has acid and alkali corrosion re-sistance,high temperature resistance,rust resistance and long service life.
04 Support customization:We have a large number of stainless steel plates and Tube in stock,which can be customized according to
your requirements.
| Name | Stainless Steel Pipe | |||||
| Standard | GB12770,GB12771,ASTM A249,ASTM A269,ASTMA270,ASTMA312,ASTMA554,JIS G 3463 | |||||
| Material Grade | 304,316,201,202,316L,430 | |||||
| Main Material | a) 201 (Ni0.8%-1%) | |||||
| b) 202 (Ni: 3.5%-4.5%) | ||||||
| c) 304 (Ni: 8% Cr: 18%) | ||||||
| d) 316 (Ni: 10% Cr: 18%) | ||||||
| Thickness | 0.5-2.0mm | |||||
| Length | 15x15,18x18,20x20,23.5x23.5 or as customers' request | |||||
| Tolerance | a)Outer Diameter; +/-0.2mm | |||||
| b)Thickness; +/-0.03mm | ||||||
| c)Length;+/-5mm | ||||||
| Surface | 180G, 320G, 400G Satin / Hairline | |||||
| 400G, 500G, 600G or 800G Mirror finish | ||||||
| Application | Electronics | |||||
| Test | Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT | |||||
| Chemical Composition of Material | Composition | 201 | 202 | 304 | 316 | 430 |
| C | ≤0.15 | ≤0.15 | ≤0.08 | ≤0.08 | ≤0.12 | |
| Si | ≤1,00 | ≤1,00 | ≤1,00 | ≤1.00 | ≤1.00 | |
| Mn | 5.5-7.5 | 7.5-10 | ≤2.00 | ≤2.00 | ≤1.00 | |
| P | ≤0.06 | ≤0.06 | ≤0.045 | ≤0.045 | ≤0.040 | |
| S | ≤0.03 | ≤0.03 | ≤0.030 | ≤0.030 | ≤0.030 | |
| Cr | 12.5-14.5 | 15-18 | 18-20 | 16-18 | 16-18 | |
| Ni | 0.8-1.5 | 46 | 8-10.5 | 1014 | ||
| Mo | 2.0-3.0 | |||||
| Mechanical Proper | Material Item | 201 | 202 | 304 | 316 | |
| Tensile Strength | ≥535 | ≥520 | ≥520 | ≥520 | ||
| Yield Strength | ≥245 | ≥205 | ≥205 | ≥205 | ||
| Extension | ≥30% | ≥30% | ≥35% | ≥35% | ||
| Hardness(HV) | <253 | <253 | <200 | <200 | ||
Stainless Steel Tube/Pipe Specification
Available Surface
Packing&Delivery
Product Test
Appplications
