316 Stainless Steel Square Tube
steel railing 316 price per kg
Normal tens of yuan per kilogram, the specific specifications of the quantity to determine the price.
Normal tens of yuan per kilogram, the specific specifications of the quantity to determine the price.
Send Inquiry
Product Introduction
316 stainless steel square tube
Heat treatment
- 316 Stainless steel cannot be overheated for hardening.
- Welding
- Typical uses Pulp and paper equipment Heat exchangers, dyeing equipment, film washing equipment, pipes, materials for the exterior of buildings in coastal areas
316 stainless steel is also resistant to Marine and aggressive industrial atmospheres. Heat resistance in the intermittent use below 1600 degrees and in the continuous use below 1700 degrees, 316 stainless steel has good oxidation resistance.
The Chemical Composition of grade 316L Stainless Steel is outlined in the following table
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| 316 | Min | - | - | - | 0 | - | 16.0 | 2.00 | 10.0 | - |
| Max | 0.08 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
| 316L | Min | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
| Max | 0.03 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
| 316H | Min | 0.04 | 0.04 | 0 | - | - | 16.0 | 2.00 | 10.0 | - |
| max | 0.10 | 0.10 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | - |
The Mechanical Properties of grade 316L Stainless Steel are displayed in the following table.
| Grade | Tensile Str (MPa) min |
Yield Str 0.2% Proof (MPa) min |
Elong (% in 50mm) min |
Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316 | 515 | 205 | 40 | 95 | 217 |
| 316L | 485 | 170 | 40 | 95 | 217 |
| 316H | 515 | 205 | 40 | 95 | 217 |
316L Stainless Steel Pipes and Tubes Physical Properties
| Grade | Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Co-eff of Thermal Expansion (µm/m/°C) | Thermal Conductivity (W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Elec Resistivity (nΩ.m) |
|||
| 0-100°C | 0-315°C | 0-538°C | At 100°C | At 500°C | |||||
| 316/L/H | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
Properties of 316L stainless steel pipe
- Density: 8.0 g/cm³
- Electrical Resistivity: 0.74 x10^-6 Ω .m.
- Elongation A50 mm: 40 Min %
- Hardness Brinell: 215 Max HB.
- Melting Point: 1400 °C.
- Modulus of Elasticity: 193 GPa.
- Proof Stress: 200 Min MPa.
- Tensile Strength: 500 - 700 MPa.
Application
SURFACE
Product Testing
Packaging & Shipping
Laser cutting tube Customized according to drawings
Detailed Photo
production flow
