Life drinking water supply pipe can use 304/316L stainless steel pipe, more safe and sanitary, household drinking water pipe is the most healthy and safe, this stainless steel water pipe can prevent the secondary pollution of water, use more assured.

Send Inquiry

Product Introduction

316l pipe tube

What is the use of stainless steel pipe 316l?

316L(18Cr-12Ni-2.5Mo low carbon) as a low C series of 316 steel, in addition to having the same characteristics as 316 steel, its resistance to grain boundary corrosion is excellent.
In the use of 316 steel, there are special requirements for products against grain boundary corrosion.

product details

Strict selection of materials: strict selection of excellent raw materials, product surface finish is good, not easy to rust, corrosion.
Solid and practical: good hardness of real material, not afraid of wind and sun, long use time.
Spot supply: perfect equipment, sufficient inventory, can receive urgent orders, timely delivery.

316L Stainless Steel Pipes Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
316L	min.	–	–	–	–	–	16.0	2.0	10.0	–
316L	max.	0.08	2.0	0.75	0.045	0.03	18.0	3.0	14.0	0.10

Stainless Steel 316L Pipe Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Rockwell B (HR B) max	Brinell (HB) max
316L	515	205	40	95	217

Stainless Steel 316L Pipes Physical Properties

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
Grade	Density (kg/m3)	Elastic Modulus (GPa)	0-1000C	0-3150C	0-5380C	at 1000C	at 5000C	Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
316L	8000	193	15.9	16.2	17.5	16.3	21.5	500	740
