ASME SA213 TP 316L Stainless Steel Tube
ASME SA213 TP 316L Stainless Steel Tube
ASME SA213 TP 316L Stainless Steel Tube
ASME SA213 TP 316L Stainless Steel Tube

ASME SA213 TP 316L Stainless Steel Tube

316A is common 316, 316L is used in low temperature environment, and 316H is used in high temperature.

Send Inquiry

Product Introduction

If it is a real 316L stainless steel material, even if it is soaked in seawater for a year, there will not be much corrosion phenomenon, so you can use it with confidence.

In addition, for stainless steel, their internal and external corrosion resistance is the same, that is, it will not quickly spread to other places because of a little corrosion on the surface, especially affecting the internal structure, in the household field, 316L stainless steel, the life is still quite long.

Our eight strengths

Direct factory operation
Quality steel
Fill with material
Full and long
Strict quality inspection
Stable performance
High resistance
Non-standard customization

Typical Chemical Composition % (max values, unless noted)
Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N
316	0.08 max	2.0 max	0.75 max	0.045 max	0.03 max	min: 16.0 max: 18.0	min: 2.0 max: 3.0	min: 10.0 max: 14.0	0.10 max
316L	0.03 max	2.0 max	0.75 max	0.045 max	0.03 max	min: 16.0 max: 18.0	min: 2.0 max: 3.0	min: 10.0 max: 14.0	0.10 max

MECHANICAL PROPERTIES:

Typical Room Temperature Mechanical Properties
Grade	Tensile Strength KSI (min.)	Yield Strength 0.2% Offset KSI (min.)	Elongation % in 2ʺ(50.8 mm)	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
316	75	30	40	217	95
316L	70	25	40	217	95
