Stainless Steel Pipe 304L
Product Description
01 Stainless steel tubes/pipes are availabie in different material, sizes,shapes, finishes etc.
02 Diversified selection:Austenitic Stainless Steel,Martensitic Stainless Steel,Ferritic Stainless Steel and Duplex stainless steel pipes of your choice.
03 Our offered pipes are acknowledged by the customers for thelr dimensional stabllity, resistance against corrosion &abrasion and durability.

Send Inquiry

Product Introduction

The advantages of 304 stainless steel faucet are: corrosion resistance, oxidation resistance, no lead, no rust, no oil, easy to clean, easy to maintain! The disadvantage is that the process is complex and the production cost is high.

Product details display

01. The inner wall is smooth/bright: the surface is polished, no black lines, no black spots, no strains, no mechanical lines, no sand holes, smooth, no feel weld is smooth, and there is nitrogen protection in the inner weld.

02. Strict tube/Excellent workmanship:
Outer diameter tolerance ±0.02MM
Diagonal tolerance of square tube is less than 0.3MM
Thickness tolerance for conventional tubes ±0.02MM
Thick pipe tolerance soil 0.05MM

03. Complete size/variety of specifications: a variety of specifications and sizes for you to choose.

04. Support customization: support deep processing, to map to sample customization, packaging can be covered with protective film, woven bag packaging.

Product Name	Inox factory SUS 316l 201 304 welded ss pipe steel tubing stainless steel pipes stainless steel tube
Shape	Round / Square / Rectangle
Production Standards	ASTM A270 , EN 10357 , DIN 11850 ,ISO 2037 , JIS G3447, KS D 3585 and so on.
Production Standards
Process Characteristics	Inner Welded Seam Removed ; Online Bright Solution Anneal ; Inner Electro Polish And Mechanical Polish ;
Application	Suitable For Industries With High Hygiene Requirements Such As Beer, Beverage, Milk, Pharmaceuticals, Etc.
Test	Flaring test ; Flattening test ; Bending Test ; Hydraulic Test ; Eddy Current test
Design	OEM / ODM / Customized
Certificate	ISO9001 ; ISO14001; ISO 18001; TUV ;

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0 .15	≤0 .75	5. 5-7. 5	≤0.06	≤ 0.03	3.5 -5.5	16 .0 -18.0	-
202	≤0 .15	≤l.0	7.5-10.0	≤0.06	≤ 0.03	4.0-6.0	17.0-19.0	-
301	≤0 .15	≤l.0	≤2.0	≤0.045	≤ 0.03	6.0-8.0	16.0-18.0	-
302	≤0 .15	≤1.0	≤2.0	≤0.035	≤ 0.03	8.0-10.0	17.0-19.0	-
304	≤0 .0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	8.0-10.5	18.0-20.0	-
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0-13.0	18.0-20.0	-
309S	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0-15.0	22.0-24.0	-
310S	≤0.08	≤1.5	≤2.0	≤0.035	≤ 0.03	19.0-22.0	24.0-26.0
316	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	10.0-14.0	16.0-18.0	2.0- 3.0
316L	≤0 .03	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0 - 15.0	16 .0 -1 8.0	2.0 - 3.0
321	≤ 0 .08	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0 - 13 .0	17.0 -1 9.0	-
630	≤ 0 .07	≤1.0	≤1.0	≤0.035	≤ 0.03	3.0-5.0	15.5-17.5	-
631	≤0.09	≤1.0	≤1.0	≤0.030	≤0.035	6.50-7.75	16.0-18.0	-
904L	≤ 2 .0	≤0.045	≤1.0	≤0.035	-	23.0·28.0	19.0-23.0	4.0-5.0
2205	≤0.03	≤1.0	≤2.0	≤0.030	≤0.02	4.5-6.5	22.0-23.0	3.0-3.5
2507	≤0.03	≤0.8	≤1.2	≤0.035	≤0.02	6.0-8.0	24.0-26.0	3.0-5.0
2520	≤0.08	≤1.5	≤2.0	≤0.045	≤ 0.03	0.19 -0. 22	0. 24 -0 . 26	-
410	≤0.15	≤1.0	≤1.0	≤0.035	≤ 0.03	-	11.5-13.5	-
430	≤0.1 2	≤0.75	≤1.0	≤ 0.040	≤ 0.03	≤0.60	16.0 -18.0
