Seamless Tubing And Pipe
Seamless tubing and pipe has become an incredibly important material in modern engineering and manufacturing. Its benefits are many, and the applications it can be used for are virtually limitless. One key advantage of seamless tubing is that it provides a smooth and consistent surface, which makes it ideal for use in precision machinery and equipment. This means that products made from seamless tubing are less prone to wear, tear, and damage over time, making them more reliable and long-lasting.
Another benefit of seamless tubing is its strength and durability. It is able to withstand high pressure and temperature, making it ideal for use in pipelines, oil and gas drilling, and other heavy-duty applications. Additionally, because seamless tubing is made without any joints or seams, it is less likely to leak or break under stress, which helps to ensure the safety and integrity of the products it is used in.
Seamless tubing is also highly customizable, with a wide variety of sizes, shapes, and materials available to suit the needs of virtually any industry or application. This means that it can be tailored to meet the specific requirements of each project, whether that means working with high-strength alloys for aerospace applications, or using more cost-effective materials for general-purpose use.
| STAINLESS STEEL PIPE, STAINLESS STEEL SEAMLESS PIPES SPECIFICATION | ||
|---|---|---|
|
Diameter of Stainless Steel Pipe |
1/2” NB – 24” NB |
|
|
Wall Thickness of Seamless Stainless Steel Pipe |
Schedule 5S – Schedule XXS (heavier on request) |
|
|
300 Series Stainless Steel Pipe Grades |
304 – 304/L – 316 – 316L |
|
|
Processing |
Cut-to-length, polishing |
|
STAINLESS STEEL PIPE DIMENSIONS AND WEIGHTS
| PIPESIZE | ODININCHES |
A.S.A. Pipe Schedules |
|||||||||||||||
|
5s |
5 |
10s |
10 |
20 |
30 |
40s& Std. |
40 |
60 |
80s& E.H. |
80 |
100 |
120 |
140 |
160 |
DBLE.H. |
||
|
1/8 |
.405 |
.035.1383 |
.049.1863 |
.049.1863 |
.068.2447 |
068.2447 |
0.95.3145 |
0.95.3145 |
|||||||||
|
1/4 |
.540 |
.049.2570 |
.065.3297 |
.065.3297 |
.088.4248 |
088.4248 |
.119.5351 |
.119.5351 |
|||||||||
|
3/8 |
.675 |
.049.3276 |
.065.4235 |
.065.4235 |
.091.5676 |
.091.5676 |
.126.7338 |
.126.7338 |
|||||||||
|
1/2 |
.840 |
.065.5383 |
.065.5383 |
.083.6710 |
.083.6710 |
.109.8510 |
.109.8510 |
.1471.088 |
.1471.088 |
.1871.304 |
.2941.714 |
||||||
|
3/4 |
1.050 |
.065.6838 |
.065.6838 |
.083.8572 |
.083.8572 |
.1131.131 |
.1131.131 |
.1541.474 |
.1541.474 |
.2181.937 |
.3082.441 |
||||||
|
1 |
1.315 |
.065.8678 |
.065.8678 |
.1091.404 |
.1091.404 |
.1331.679 |
.1331.679 |
.1792.172 |
.1792.172 |
.2502.844 |
.3583.659 |
||||||
|
1-1/4 |
1.660 |
.0651.107 |
.0651.107 |
.1091.806 |
.1091.806 |
.1402.273 |
.1402.273 |
.1912.997 |
.1912.997 |
.2503.765 |
.3825.214 |
||||||
|
1-1/2 |
1.900 |
.0651.274 |
.0651.274 |
.1092.085 |
.1092.085 |
.1452.718 |
.1452.718 |
.2003.631 |
.2003.631 |
.2814.859 |
.4006.408 |
||||||
|
2 |
2.375 |
.0651.604 |
.0651.604 |
.1092.638 |
.1092.638 |
.1543.653 |
.1543.653 |
.2185.022 |
.2185.022 |
.3437.444 |
.4369.029 |
||||||
|
2-1/2 |
2.875 |
.0832.475 |
.0832.475 |
.1203.531 |
.1203.531 |
.2035.793 |
.2035.793 |
.2767.661 |
.2767.661 |
.37510.01 |
.55213.70 |
||||||
|
3 |
3.500 |
.0833.029 |
.0833.029 |
.1204.332 |
.1204.332 |
.2167.576 |
.2167.576 |
.30010.25 |
.30010.25 |
.43714.32 |
.60018.58 |
||||||
|
3-1/2 |
4.000 |
.0833.472 |
.0833.472 |
.1204.973 |
.1204.973 |
.2269.109 |
.2269.109 |
.31812.51 |
.31812.51 |
.63622.85 |
|||||||
|
4 |
4.500 |
.0833.915 |
.0833.915 |
.1205.613 |
.1205.613 |
.23710.79 |
.23710.79 |
.28112.66 |
.33714.98 |
.33714.98 |
.43719.01 |
.53122.51 |
.67427.54 |
||||
|
4-1/2 |
5.000 |
.24712.53 |
.35517.61 |
.71032.53 |
|||||||||||||
|
5 |
5.563 |
.1096.349 |
.1096.349 |
.1347.770 |
.1347.770 |
.25814.62 |
.25814.62 |
.37520.78 |
.37520.78 |
.50027.04 |
.62532.96 |
.75038.55 |
|||||
|
6 |
6.625 |
.1097.585 |
.1097.585 |
.1349.290 |
.1349.290 |
.28018.97 |
.28018.97 |
.43228.57 |
.43228.57 |
.56236.39 |
.71845.30 |
.86453.16 |
|||||
|
7 |
7.625 |
.30123.57 |
.50038.05 |
.87563.08 |
|||||||||||||
| Medium Type = Wall thickness in inchesBold Type = Steel weight per foot in pounds | |||||||||||||||||
