STAINLESS STEEL 316L PIPE Ø 28 LENGTH 6M

STAINLESS STEEL 316L PIPE Ø 28 LENGTH 6M

316L stainless steel pipe is a kind of hollow long circular steel, mainly widely used in petroleum, chemical, medical, food, light industry, mechanical instrumentation and other industrial transportation pipes and mechanical structural components. In addition, the bending and torsional strength are the same, and the weight is light, so it is also widely used in the manufacture of mechanical parts and engineering structures.

ASTM A312 tp316L Pipe Equivalent Grades

UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
	BS	En	No	Name
S31603	304S11	58E	1.4436	X3CrNiMo17-13-3	2348	SUS 316L

sus 316L Stainless Steel Pipe Composition

	C	Mn	Si	P	S	Cr	Mo	Ni	N
min.	–	–	–	–	–	16.0	2.0	10.0	–
max.	0.08	2.0	0.75	0.045	0.03	18.0	3.0	14.0	0.10

316L grade Stainless Steel Pipe Mechanical & Physical Properties

Mechanical Properties

Tensile Stress (MPa) min	Yield Stress 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
			Rockwell B (HR B) max	Brinell (HB) max
515	205	40	95	217

Physical Properties

Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
		0-1000C	0-3150C	0-5380C	at 1000C	at 5000C
8000	193	15.9	16.2	17.5	16.3

Application

Packing & Delivery

SURFACE

Product Testing
