316L stainless steel pipe pressure calculation
The pressure formula P=2SR/D is inferred
P= Pressure MPA S= Yield strength of steel grade 50% (50% for welded pipe, 40% for seamless pipe)

Send Inquiry

Product Introduction

The essential difference between 316SS and 316L,
316SS is low carbon austenitic stainless steel,
The carbon content is 0.08,
And 316L is ultra-low carbon steel,
The carbon content is 0.03,

product feature

Modern storage: to provide customers with quality service.
Full range of products: to provide customers with quality service.
Any zero cut: product workmanship is meticulous, support retail cutting, the incision is smooth and smooth.
Perfect after-sales service: For your satisfaction, any questions can contact us at any time to serve you.

Stainless Steel Round Tube 316L Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
316L	515	205	40	95	217

ASTM A269 TP 316L Stainless Steel Seamless Tubes Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
316L	min.	–	–	–	–	–	16.0	2.0	10.0	–
316L	max.	0.08	2.0	0.75	0.045	0.03	18.0	3.0	14.0	0.10

316L Stainless Steel Seamless Tubes Physical Properties

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
			0-1000C	0-3150C	0-5380C	at 1000C	at 5000C
316L	8000	193	15.9	16.2	17.5	16.3	21.5	500	740
