Stainless steel 316 is one of the most popular and hot selling types of steel in the market. Here are some reasons why:
Excellent corrosion resistance
High strength and durability
Versatility
Low maintenance
Aesthetic appeal

Send Inquiry

Product Introduction

316 Inox Stainless Steel Sheet is an excellent choice for applications that require resistance to corrosion, high temperatures, and challenging environments. It is available in various forms, including sheets, plates, and coils, and can be cut and shaped to fit unique needs.

Material: 316 stainless steel
Thickness: 0.3-3.0mm
Width: 1000-1500mm
Length: 2000-6000mm
Surface treatment: 2B, BA, HL, NO.4, etc
Tensile strength: ≥520 MPa
Yield strength: ≥205 MPa
Elongation: ≥40%
Hardness: ≤187HB; ≤90HRB; ≤200HV
Corrosion resistance: excellent, excellent performance in seawater and chemical media

Chemical Composition

		Carbon	Silicon	Manganese	Phosphorus	Sulphur	Nickel	Chromium	Molybdenum	Nitrogen
316	Specification (max)	0.08	0.75	2.00	0.045	0.030	10.00 - 14.00	16.00 - 18.00	2.00 - 3.00	0.10
	(typical)	0.037	0.45	1.60	0.032	0.007	10.72	16.95	2.12	0.031
316L	Specification (max)	0.03	0.75	2.00	0.045	0.030	10.00 - 14.00	16.00 - 18.00	2.00 - 3.00	0.10
	(typical)	0.020	0.49	1.54	0.030	0.004	10.70	17.00	2.12	0.037
316H	Specification (max)	0.04 - 0.10	0.75	2.00	0.045	0.030	10.00 - 14.00	16.00 - 18.00	2.00 - 3.00	-
	(typical)	0.050	0.37	1.67	0.033	0.009	10.69	16.90	2.13	0.025

Mechanical Properties

		0.2% Proof Stress	Tensile Strength	Elongation	Hardness
		MPa	MPa	%	HB (max)
316	Specification (min)	>= 205	>= 520	>= 40	<= 217
316	typical values	270	600	55	145

304L	Specification (min)	>= 170	>= 485	>= 40	<= 217
304L	typical values	270	600	55	145

304H	Specification (min)	>= 205	>= 515	>= 40	<= 217
304H	typical values	270	600	55	145
