316 Perforated Sheet
316 perforated sheet is a high-quality metal sheet that is widely used in various industrial sectors due to its excellent strength, durability, and corrosion resistance properties. The sheet has small holes that are evenly spaced apart, which allows it to filter light and air while providing good visibility and security.
One of the great advantages of 316 perforated sheet is its versatility and flexibility. It can be easily cut, welded, and shaped into various shapes and sizes to meet specific project requirements. Additionally, the sheet can be coated with different materials such as powder coating or anodizing to enhance its aesthetic appeal and improve its durability.
Moreover, 316 perforated sheet is an eco-friendly and sustainable option for industrial applications. The metal is completely recyclable and can be reused indefinitely without losing its quality or performance. This significantly reduces waste and minimizes the environmental impact of industrial processes.
Another great feature of 316 perforated sheet is its low maintenance requirements. The sheet is resistant to corrosion, rust, and stains, so it requires minimal cleaning and upkeep. This makes it an ideal option for industrial settings where frequent cleaning and maintenance can be time-consuming and expensive.
Available Grades of Stainless Steel
Stainless steel is a popular and versatile material that is widely used in a variety of applications, from household appliances, cookware, and cutlery to construction and industrial equipment. Its durability, corrosion resistance, and attractive appearance make it an excellent choice for many projects. Stainless steel sheet is a form of this material that is widely used for decorative or functional purposes.
Stainless steel sheet comes in various grades, each with its unique properties. There are hundreds of grades of stainless steel available on the market, but the most common ones are:
1. 304 – This is the most commonly used grade of stainless steel sheet. It is also known as 18/8 stainless steel because it contains 18% chromium and 8% nickel. It is highly corrosion-resistant and can withstand high temperatures. It is also easy to form and weld.
2. 316 – This grade contains 16% chromium and 10% nickel, as well as 2% molybdenum. It is highly corrosion-resistant, especially in marine environments, and is also resistant to acids and high temperatures. It is commonly used in applications such as chemical processing equipment, medical devices, and marine equipment.
3. 430 – This is a ferritic grade of stainless steel that contains 17% chromium. It is magnetic and has good heat and corrosion resistance. It is commonly used for decorative purposes, such as in automotive trim and kitchen equipment.
4. 201 – This grade contains less nickel than 304 but more manganese and nitrogen. It is a cheaper alternative to 304 but has lower corrosion resistance. It is commonly used in applications that do not require high corrosion resistance, such as cookware, flashings, and trims.
In conclusion, stainless steel sheet comes in various grades, each with its unique properties and uses. Choosing the right grade for your application is crucial to ensure the best performance, durability, and aesthetics of the product. Consult with a reputable stainless steel supplier or expert to help you determine the best grade for your needs.
SS 316/316L Plate, Sheet & Coil Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|
| SS 316 | 0.08 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| SS 316L | 0.035 max | 2 max | 1.00 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
Stainless Steel 316/316L Sheets, Plates & Coils Mechanical Properties
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| SS 316L | 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Equivalent Grades for 316/316L Stainless Steel Sheets & Plates
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
HOW TO MEASURE:
Measuring a 316 perforated sheet is important to ensure that it fits into the project requirements. Here's how to do it:
1. Measure the length and width of the sheet: Use a measuring tape to measure the length and width of the sheet. Make sure to measure the actual sheet size, not the size of the holes.
2. Determine the thickness of the sheet: Use a micrometer to measure the thickness of the sheet. This is important because the thickness of the sheet will affect its weight and strength.
3. Count the number of holes: Count the number of holes in the sheet to ensure that it meets the project requirements. If the number of holes is not sufficient or too many, the sheet may need to be replaced.
4. Measure the size of the holes: If the size of the holes is important, use a caliper or ruler to measure the diameter or size of the holes.
5. Check the spacing: The spacing of the holes should also be measured. Usually, the spacing is specified as the distance between the centers of adjacent holes.
It is important to measure the 316 perforated sheet accurately to ensure that it fits the project requirements and to avoid any unnecessary hassle or delay. With these simple steps, you can measure the sheet and ensure that it is the correct size and specifications for your project.
