316l Steel Sheets
316L stainless steel sheets, also known as surgical stainless steel, are a widely used material in many industries due to their strength, durability, and corrosion resistance. These sheets are made of a low carbon version of stainless steel, which makes them easier to form, weld and work with compared to other types of stainless steel.
There are numerous benefits of using 316L stainless steel sheets. Firstly, they are resistant to corrosion and staining from chemicals, heat, and saltwater, which makes them ideal for use in harsh environments such as marine applications and chemical processing plants. Secondly, they have excellent strength and toughness properties, which make them an ideal choice for making components such as machinery parts, pressure vessels, and structural beams.
Additionally, 316L stainless steel sheets have good weldability, meaning they can be easily joined together to form complex assemblies. They also have a low carbon content, which means they are less likely to corrode or become brittle over time, making them a reliable and long-lasting option for many industries.
| Product | Hot rolled stainless steel plate | Cold rolled stainless steel plate |
| Thickness | 3.0mm-200mm | 0.3mm-6.0mm |
| Width | 1240mm/1500mm/1800mm/2000mm/2200mm | 1000mm/1219mm/1500mm |
| Length | 2438mm/6000mm or as client's requirement | 2000mm/2439mm/3000mm oras per client's requirement |
| Surface Finish | No.1,HL,No.4,8K | 2B,BA,No.1,No.4,No.8,8K,mirror,checkered,embossed,hairline,sand blast,stain brush,etching,etc. |
| Grade | 304,304L,304J1,321,316L,316Ti,317L,347H,310S,309S,904L,2205 | 304,304L,304J1,321,316L,316Ti,317L,347H,310S,309S,904L,2205 |
| Standard | ASTM,JIS,SUS,GB,DIN | ASTM,JIS,SUS,GB,DIN |
| Packing | Standard export packing for stainless steel sheet:1.surface polish, 2:bundle package, 3:wooden case,wooden pallet package, 4:container or bulk,5:special according to customer's request | |
| Application | Stainless Steel Sheet are widely used in below fields:1.Construction field,shipping building industry 2.Petroleum and Chemical Industries3.Food and Mechanical Industries 4.Boiler Heat Exchange5.Machinery and Hardware Industries | |
Stainless Steel 316 sheet Equivalent Grades
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | Z7CND17‐11‐02 | 316S31 / 316S33 | - | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Chemical Properties Of 316 Stainless Steel sheet:
|
Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
Fe |
|
|
316 min 316 max |
- 0.08 |
- 2.0 |
- 1.00 |
0 0.045 |
- 0.03 |
16.00 18.00 |
2.00 3.00 |
11.0 14.0 |
67.845 |
Stainless Steel 316 Grade Specification Comparision
|
Grade |
UNS No |
Old British |
Euronorm |
Swedish SS |
Japanese JIS |
|||
|
BS |
En |
No |
Name |
|||||
|
316 |
S31600 |
316S31 |
58H,58J |
1.4401 |
X5CrNiMo17-12-2 |
2347 |
SUS 316 |
|
Mechanical Properties Of 316 Stainless Steel sheet:
The mechanical properties of grade 316 Stainless Steel sheet are displayed in the following table.
|
Grade |
Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min |
Hardness |
||
|
Rockwell B (HR B) max |
Brinell (HB) |
|||||
|
316 |
515 |
205 |
40 |
95 |
217 |
|
Stainless Steel 316 sheet Physical Properties
|
Grade |
Density (kg/m3) |
Elastic Modulus (GPa) |
Mean Coefficient of Thermal Expansion(μm/m/°C) |
Thermal Conductivity(W/m.K) |
Specific Heat 0-100°C (J/kg.K) |
Electrical Resistivity (nΩ.m) |
||||
|
0-100°C |
0-315°C |
0-538°C |
at 100°C |
at 500°C |
||||||
|
316 |
8000 |
193 |
15.9 |
16.2 |
17.5 |
16.3 |
21.5 |
500 |
740 |
|
316 Stainless Steel sheet Application
1. Construction Industry
2. Marine Industry
3. Food and Beverage Industry
4. Medical Industry
5. Aerospace Industry
316 Stainless Steel sheet Processing
- Cutting
- Bending
- Welding
- Polishing
- Surface treatment
Packaging:
- Boxes and Crates
- Shrink-wrapped
- Carton boxes
- Wooden pallets
- Wooden boxes
- Wooden crates
Testings (Destructive, Non Destructive):
316 stainless steel sheet is a popular choice for a variety of industries due to its corrosion resistance and strength properties. When it comes to testing the quality of this type of stainless steel sheet, both destructive and nondestructive methods can be utilized. In this article, we will explore the different types of testing involved in thoroughly examining 316 stainless steel sheets.
Destructive testing involves damaging the material to see how it will react under certain conditions. Here are a few types of destructive testing that can be used on 316 stainless steel sheets:
1. Tensile testing: This test measures the maximum amount of force the sheet can withstand before breaking. It helps in determining the ultimate strength, yield strength, and elongation of the sheet.
2. Hardness testing: This test determines the hardness of the sheet by measuring the resistance of the material to indentation. This helps in understanding the strength of the sheet.
3. Impact testing: This test involves striking the sheet with a heavy object to see how well it can absorb the impact. This helps determine how brittle or ductile the material is.
Nondestructive testing, on the other hand, involves examining the material without causing any damage to it. Here are a few types of nondestructive testing that can be used on 316 stainless steel sheets:
1. Ultrasonic testing: This test measures the thickness and internal structure of the sheet by passing ultrasonic waves through the material. This helps in detecting any flaws or defects within the material.
2. Eddy current testing: This test detects any surface defects on the sheet by creating an electromagnetic field around the sheet and detecting any changes in the field.
3. X-ray radiography: This test uses X-rays to create an image of the internal structure of the material. This helps in detecting any cracks or voids within the material.
