Aisi 310s Data Sheet
AISI 310S is a heat-resistant stainless steel that is commonly used in high-temperature environments such as furnaces and chemical processing plants. This material is known for its excellent corrosion resistance and ability to handle extreme temperatures.
The majority of AISI 310S's composition is made up of iron, chromium, and nickel, with a small amount of carbon and other elements. The material's high chromium content gives it outstanding oxidation resistance and increases its ability to resist corrosion in harsh environments.
AISI 310S's impressive resistance to thermal shock, which can deteriorate other metals under prolonged exposure to high temperatures, makes it an ideal material choice for applications that require resistance to heat and thermal cycling.
This material is also popular in the chemical industry thanks to its excellent resistance to attack by oxidizing and reducing acids and other corrosive chemicals. Its ability to withstand high-temperature steam and gas exposure expands its use in power generation plants and waste incineration facilities.
AISI 310S's mechanical properties make it a suitable option for use in high-stress industrial applications that demand temperature resistance. This material can withstand extreme temperatures up to 1200°C, ensuring reliability in high-temperature service environments.
SS 310 / 310S / 310H SHEET & PLATE SPECIFICATIONS:
| Dimensions | : | ASTM, ASME and API |
|---|---|---|
| Standard | : | ASTM A240 / ASME SA240 |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, |
| Thickness | : | 4mm-100mm |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Surface Finish | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc |
CHEMICAL COMPOSITION OF SS 310 / 310S / 310H SHEETS AND PLATES
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24 – 26 | 0.10 max | 19 – 21 | 54.7 min |
| SS 310S | 0.08 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24 – 26 | 0.75 max | 19 – 21 | 53.095 min |
| SS 310H | 0.04 – 0.1 | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24 – 26 | – | 19 – 21 | 53.885 min |
EQUIVALENT GRADES FOR STAINLESS STEEL 310 / 310S / 310H SHEETS & PLATES
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | – | X15CrNi25-20 |
| SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | – | X8CrNi25-21 |
| SS 310H | – | S31009 | – | – | – | – | – |
MECHANICAL PROPERTIES FOR SS 310 / 310S / 310H SHEETS & PLATES
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
APPLICATION
1. High Temperature Applications: AISI 310S stainless steel is highly resistant to heat and can be used in applications that require high temperature resistance. It is commonly used in furnace parts, heat exchangers, and kilns.
2. Corrosion Resistance: AISI 310S stainless steel offers excellent resistance to corrosion in many environments. It is particularly resistant to sulfur-containing gases, making it ideal for use in refineries and petrochemical plants.
3. Weldability: This stainless steel alloy has good weldability and can be welded using various techniques such as resistance welding, arc welding, and gas tungsten arc welding (GTAW).
4. Machinability: AISI 310S stainless steel has good machinability, making it easy to shape, form, and machine. It can be drilled, bent, and cut using standard machining techniques.
5. Chemical Composition: AISI 310S stainless steel contains a high amount of chromium and nickel, which gives it superior strength and resistance to corrosion. It also contains small amounts of carbon, silicon, manganese, and phosphorus.
6. Durability: Due to its high resistance to heat and corrosion, AISI 310S stainless steel is highly durable and offers a long service life. It is commonly used in industrial applications where durability and resistance to wear are essential.
