Ss 316 Sheet

There are endless benefits to using stainless steel 316 sheet for your next project. From its strength and durability to its versatility and affordability, this material is a top choice for anyone looking for a high-quality, reliable, and long-lasting sheet metal material. So why wait? Start exploring the possibilities today!
Send Inquiry
Product Introduction

Stainless Steel 316 Sheet: The Perfect Choice for Your Next Project

If you're in the market for a high-quality sheet metal material, then look no further than stainless steel 316 sheet. This versatile material has many fantastic properties that make it an excellent choice for an array of different applications.

Strength and Durability

One of the primary benefits of using stainless steel 316 sheet is its incredible strength and durability. This material is made up of a combination of chromium, nickel, and molybdenum, making it incredibly resilient to corrosion, oxidation, and rust. Additionally, it's incredibly tough, meaning it can withstand a lot of wear and tear without showing signs of wear.

Versatility

Another significant advantage of stainless steel 316 sheet is its versatility. It can be used in an array of different applications, including industrial machinery, architectural features, and even household appliances. It has a sleek, polished look that's perfect for any modern design or aesthetic.

Easy to Maintain

Stainless steel 316 sheet is also effortless to maintain, making it an ideal material for busy commercial settings or households. It's resistant to buckling, warping, and other types of damage, making it easy to clean and keep looking great for years to come.

Affordable

While stainless steel 316 sheet is a high-quality material, it's surprisingly affordable. It's one of the most cost-effective sheet metal options out there, which makes it an excellent choice for businesses or individuals working on a tight budget.

Final Thoughts

316 plate

316 Stainless Steel Plate Specification

Product Type SS 316 Sheet, SS 316 Plate
Specification and Material Grade ASTM A240 / ASME SA240 Grade 316
Tolerances (thickness & width)

EN 10258/ DIN 59381)

EN 10151 ASTM A240 316 SS Strips

EN 10088 316 Stainless Steel strips

Americam / European Standard

ASTM A 480

ASTM A 959

ASME IID

EN ISO 9445

EN ISO 18286

EN 10051

EN 10088-1

ISO 15510

Available Sizes

Cold rolled ASTM A240 Grade 316 Stainless Steel Sheet 0.5-6.4 mm

Hot rolled ASTM A240 Grade 316 Stainless Steel Sheet 3.0–10.0 mm

Thickness 0.1 to 100 mm Thk
Width 10-2500mm
Length 2m, 2.44m, 3m, or as required
Finish 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc.
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard
Form Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate Manufacturer and Supplier

316 Stainless Steel Sheet Mechanical Properties

ASTM A240 Melting Range Psi / Mpa - Tensile Strength Psi / Mpa - Yield Strength (0.2%Offset) Density % Elongation
ASTM A240 Gr 316 1400 °C (2550 °F) MPa – 515
Psi – 75000
MPa – 205
Psi – 30000
8.0 g/cm3 35 %

SS 316 Plate Chemical Composition

ASME SA 240 C Si P N Mn S Mo Cr Ni
SA 240 316 0.08 max 1.0 max 0.045 max 67.845 min 2 max 0.030 max 2.00 – 3.00 16.00 – 18.00 11.00 – 14.00

SA 240 Gr 316 Equivalent

Grade WERKSTOFF UNS BS JIS AFNOR GOST EN
SS 316 1.4401 / 1.4436 S31600 316S31 / 316S33 SUS 316 Z7CND17‐11‐02 X5CrNiMo17-12-2 / X3CrNiMo17-13-3

ASTM A240 316 SS Sheet types

1. Hot Rolled 316 SS Sheet

2. Cold Rolled 316 SS Sheet

3. Brushed 316 SS Sheet

4. Polished 316 SS Sheet

5. Embossed 316 SS Sheet

316 2b stainless steel

3mm 316 stainless steel sheet

316l steel sheets
