Stainless Steel 316 Sheet: The Perfect Choice for Your Next Project
If you're in the market for a high-quality sheet metal material, then look no further than stainless steel 316 sheet. This versatile material has many fantastic properties that make it an excellent choice for an array of different applications.
Strength and Durability
One of the primary benefits of using stainless steel 316 sheet is its incredible strength and durability. This material is made up of a combination of chromium, nickel, and molybdenum, making it incredibly resilient to corrosion, oxidation, and rust. Additionally, it's incredibly tough, meaning it can withstand a lot of wear and tear without showing signs of wear.
Versatility
Another significant advantage of stainless steel 316 sheet is its versatility. It can be used in an array of different applications, including industrial machinery, architectural features, and even household appliances. It has a sleek, polished look that's perfect for any modern design or aesthetic.
Easy to Maintain
Stainless steel 316 sheet is also effortless to maintain, making it an ideal material for busy commercial settings or households. It's resistant to buckling, warping, and other types of damage, making it easy to clean and keep looking great for years to come.
Affordable
While stainless steel 316 sheet is a high-quality material, it's surprisingly affordable. It's one of the most cost-effective sheet metal options out there, which makes it an excellent choice for businesses or individuals working on a tight budget.
Final Thoughts
316 Stainless Steel Plate Specification
Product Type | SS 316 Sheet, SS 316 Plate |
---|---|
Specification and Material Grade | ASTM A240 / ASME SA240 Grade 316 |
Tolerances (thickness & width) |
EN 10258/ DIN 59381) EN 10151 ASTM A240 316 SS Strips EN 10088 316 Stainless Steel strips |
Americam / European Standard |
ASTM A 480 ASTM A 959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
Available Sizes |
Cold rolled ASTM A240 Grade 316 Stainless Steel Sheet 0.5-6.4 mm Hot rolled ASTM A240 Grade 316 Stainless Steel Sheet 3.0–10.0 mm |
Thickness | 0.1 to 100 mm Thk |
Width | 10-2500mm |
Length | 2m, 2.44m, 3m, or as required |
Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
Form | Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate Manufacturer and Supplier |
316 Stainless Steel Sheet Mechanical Properties
ASTM A240 | Melting Range | Psi / Mpa - Tensile Strength | Psi / Mpa - Yield Strength (0.2%Offset) | Density | % Elongation |
---|---|---|---|---|---|
ASTM A240 Gr 316 | 1400 °C (2550 °F) | MPa – 515 Psi – 75000 |
MPa – 205 Psi – 30000 |
8.0 g/cm3 | 35 % |
SS 316 Plate Chemical Composition
ASME SA 240 | C | Si | P | N | Mn | S | Mo | Cr | Ni |
---|---|---|---|---|---|---|---|---|---|
SA 240 316 | 0.08 max | 1.0 max | 0.045 max | 67.845 min | 2 max | 0.030 max | 2.00 – 3.00 | 16.00 – 18.00 | 11.00 – 14.00 |
SA 240 Gr 316 Equivalent
Grade | WERKSTOFF | UNS | BS | JIS | AFNOR | GOST | EN |
---|---|---|---|---|---|---|---|
SS 316 | 1.4401 / 1.4436 | S31600 | 316S31 / 316S33 | SUS 316 | Z7CND17‐11‐02 | – | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
ASTM A240 316 SS Sheet types
1. Hot Rolled 316 SS Sheet
2. Cold Rolled 316 SS Sheet
3. Brushed 316 SS Sheet
4. Polished 316 SS Sheet
5. Embossed 316 SS Sheet
