Abrex 400 Wear Resistant Plates
Thickness: 4mm~62mm
Width: 2000mm
Length: 8000mm
Abrex 400 Wear Resistant Plates
Wear-resistant plate is a kind of weather-resistant steel plate, some belong to alloy, some belong to boiler plate, it is a type of atmospheric corrosion resistance, between ordinary steel and stainless steel, belongs to a kind of low alloy. This is mainly because copper or nickel is also added to the steel element, which has the effect of corrosion resistance. Whether it is its ductility or corrosion properties, compressive properties are very prominent, according to research shows that its weather resistance is 8 times that of ordinary steel is very simple.
400 wear-resistant plate hardness requirements should be between 360 and 440.
product use
- Metallurgy
- coal
- cement
- electricity
- glass
- mining
- Mountains
- building materials
- bricks
Chemical Composition of NM400
| Brand | C | Si | Mn | P | S | Cr | Mo | Ni | B | CEV |
|---|---|---|---|---|---|---|---|---|---|---|
| NM400 | ≤0.24 | ≤0.50 | ≤1.6 | ≤0.025 | ≤0.015 | 0.4~0.8 | 0.2~0.5 | 0.2~0.5 | ≤0.005 |
Mechanical Property of NM400
| Brand | Thickness mm | Tensile Test MPa | Hardness | |||||||
|---|---|---|---|---|---|---|---|---|---|---|
| YS Rel MPa | TS Rm MPa | Elongation % | ||||||||
| NM400 | 10-50 | ≥620 | 725-900 | ≥16 | 380-460 | |||||
Application
