Naming :N is the first pinyin letter of "resistant" in "wear-resistant".
M is the first pinyin letter for "wear" in "wear".
500 is the Brinell Hardness number HB value. (500 hardness value is a broad sense, the domestic NM500 hardness value is about 500.)
NM500 wear-resistant steel plate is widely used in engineering machinery, environmental protection machinery, metallurgical machinery, abrasive tools, bearings and other product parts.

Send Inquiry

Product Introduction

NM 500 STEEL PLATE

NM500 is a high-strength wear-resistant steel plate, which has a high anti-wear ability, NM500 wear-resistant steel plate is mainly used in mining machinery and other equipment, often used for friction and impact of the key wear-resistant contact surface used.

Naming :N is the first pinyin letter of "resistant" in "wear-resistant".

M is the first pinyin letter for "wear" in "wear".

500 is the Brinell Hardness number HB value. (500 hardness value is a broad sense, the domestic NM500 hardness value is about 500.)

Execution standard: GB/T 24186-2009

Class classification :NM500ANM500B

Heat treatment: tempering (quenching + tempering).

Tensile direction: transverse

Tensile strength: ≥1250(1650)

Elongation A50% : ≥8

Chemical Elements

Steel Grade	C	Si	Mn	P	S	Cr	Mo	Ni	Ti
NM300/AR300	0.23	0.70	1.60	0.025	0.015	0.70	0.40	0.50	0.050
NM360/AR360	0.25	0.70	1.60	0.025	0.015	0.80	0.50	0.50	0.050
NM400/AR400	0.30	0.70	1.60	0.025	0.010	1.00	0.50	0.70	0.050
NM450/AR450	0.35	0.70	1.70	0.025	0.010	1.10	0.55	0.80	0.050
NM500/AR500	0.38	0.70	1.70	0.020	0.010	1.20	0.65	1.00	0.050
NM550/AR550	0.38	0.70	1.70	0.020	0.010	1.20	0.70	1.00	0.050
NM600/AR600	0.38	0.70	1.90	0.020	0.010	1.50	0.70	1.00	0.050

Mechanical Property

mark	thickness	strength of extension	ductility	—20℃Impact work (longitudinal）AKV/J	Brinell HardnessHBW	cold bend
NM500	6～60	—	—	≥24	480～525	Sample width B=30MM bending Angle 180° Bending center diameter dw4n
