C60 Medium Carbon Steel Bar
C60 medium carbon steel bar is a high-quality steel product with excellent strength and durability. It is widely used in various industries, such as construction, automotive, and aerospace. This steel grade is known for its excellent toughness, wear resistance, and corrosion resistance, making it an ideal choice for demanding applications.
One of the significant advantages of C60 steel is its high carbon content, which makes it capable of withstanding extreme temperature and pressure conditions without losing its strength or ductility. This steel grade is known for its excellent hardness and toughness, which makes it ideal for use in heavy-duty machinery and equipment.
C60 medium carbon steel bar is also known for its excellent machinability, which makes it easy to work with. The steel can be easily welded, bent, and shaped to meet various requirements. Furthermore, it is readily available in a range of sizes and shapes, making it a versatile material suitable for different applications.
In summary, C60 medium carbon steel bar is a high-quality steel product that offers excellent strength, durability, and wear resistance. It is an ideal choice for demanding applications in different industries. Its versatility and easy machinability make it a popular choice for various manufacturing processes. It is a reliable and cost-effective solution that can withstand even the harshest conditions.
Chemical Composition
| Grade | C | Mn | P | S | Si | Cr | Mo | Ni | Cr+Mo+Ni |
| C60/1.0601 | 0.57-0.65 | 0.60-0.90 | ≤ 0.045 | ≤ 0.045 | ≤ 0.4 | ≤ 0.4 | ≤ 0.1 | ≤ 0.4 | ≤ 0.63 |
| C60E/1.1221 | 0.57-0.65 | 0.60-0.90 | ≤ 0.03 | ≤ 0.035 | ≤ 0.4 | ≤ 0.4 | ≤ 0.1 | ≤ 0.4 | ≤ 0.63 |
| C60R/1.1223 | 0.57-0.65 | 0.60-0.90 | ≤ 0.03 | 0.02-0.04 | ≤ 0.4 | ≤ 0.4 | ≤ 0.1 | ≤ 0.4 | ≤ 0.63 |
Relevant Standards
| USA | UK | China | Japan | Australia |
| 1060 | 070M60 | 60# | S60C | 1060 |
Mechanical Property
| Mechanical properties a at room temperature in the quenched and tempered condition (+QT) | |||
| Diameter d mm | ≤ 16 | 16-40 | 40-100 |
| Thickness t mm | < 8 | 8-20 | 20-60 |
| Yield Strength Mpa | ≥580 | ≥520 | ≥450 |
| Tensile Strength Mpa | 850-1000 | 800-950 | 750-900 |
| Elongation, % | ≥11 | ≥13 | ≥14 |
| Reduction of area ,% | ≥25 | ≥30 | ≥35 |
| Mechanical properties a at room temperature in the normalized condition (+N) | |||
| Diameter d mm | ≤ 16 | 16-100 | 100-250 |
| Thickness t mm | ≤ 16 | 16-100 | 100-160 |
| Yield Strength Mpa | ≥380 | ≥340 | ≥310 |
| Tensile Strength Mpa | ≥710 | ≥670 | ≥650 |
| Elongation, % | ≥10 | ≥11 | ≥11 |
Guideline value Curve for C60 Steel Mechanical Property
X:Tempering temperature,oC
Y:Tensile and Yield Strength,Mpa
Z:Elongation and Reduction in area,%
Surface Hardness
Treated to improve shearability (+S):Max 255HB
Soft annealed (+A):Max 241HB
| NORMAL HARDENABILITY +H (Hardness HRC – distance mm) | ||||||||||||||||
| HRC - mm | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 13 | 15 | 20 | 25 | 30 |
| MAX | 67 | 66 | 65 | 63 | 62 | 59 | 54 | 47 | 39 | 37 | 36 | 35 | 34 | 33 | 31 | 30 |
| MIN | 60 | 57 | 50 | 39 | 35 | 33 | 32 | 31 | 30 | 29 | 28 | 27 | 26 | 25 | 23 | 2 |
Application
1. Automobile Industry:commonly used in the automobile industry for making components such as camshafts, gears, and crankshafts. The high strength and durable properties of this steel make it an ideal choice for these applications.
2. Construction Industry: used in the construction industry for making various components such as beams, columns, and girders. The high tensile strength of this steel makes it an excellent choice for structural applications.
3. Manufacturing Industry: used in the manufacturing industry for making machine parts, tools, and dies. The excellent machinability and wear resistance properties of this steel make it an ideal choice for these applications.
4. Aerospace Industry: also used in the aerospace industry for making components such as landing gear, engine parts, and structural components. The high strength and durability properties of this steel make it an ideal choice for these applications.
5. Energy Industry: used in the energy industry for making components such as turbine blades, generators, and pumps. The high strength and corrosion resistance properties of this steel make it an excellent choice for these applications.
