S45c Metal

(1)S45C is Japanese standard JIS G4051-79(94), high quality carbon steel, the use of electric furnace, open furnace or pure oxygen converter steelmaking process made of all static steel, with uniform quality, no defects and other characteristics. The carbon content of the steel is ≥0.4%, excellent wear resistance, but the ductility is reduced, and the quenching is easy to deformation and cracking, so the heat treatment is extremely important, and it must be cooled after the fire to avoid the occurrence of temper brittleness. The machinability of such carbon steel can be improved by spheroidizing treatment.

(2) Supply state hardness 137~170HBS, 167~229HBS, 201~269HBS. (3) Chemical composition of S45C (mass fraction, %)C 0.42~0.48, Si 0.15~0.35, Mn 0.60~ 0.90P ≤0.030, S≤0.035, Cu≤0.30, Ni≤0.20, Cr≤0.20

(4) Refer to the corresponding steel number China GB standard steel number 45, German DIN standard material number 1.0503, Germany DIN standard steel C45, French AFNOR standard steel C45, French NF standard steel C45, Italian UN standard steel C45, Belgian NBN standard steel C45-1, Swedish SS standard steel 1650, Spanish UNE standard steel F114, American AISI/SAE standard steel 1045, International standardization Group ISO standard steel number C45E4, Japanese JIS standard steel number S45C/S48C, British BS standard steel number IC45/080A47.

(5) Quenching and tempering specification Quenching temperature 820~870℃, water cooling, tempering temperature 550~650℃, hot cooling.

(6) Mechanical property parameters of S45C: tensile strength >686MPa, yield strength >490MPa, elongation >17%, shrinkage >45%, impact toughness >78J/cm, hardness 201~269HB.

(7) Typical application examples ① mainly used in the manufacture of plastic molds and molds. ② Standard template materials, etc.
