SAE 1055 SAE J 403

SAE 1055 SAE J 403

SAE 1055 is a high-quality carbon steel that is widely used in the manufacture of machine parts, automotive parts, tools and forgings. The physical properties and chemical properties of the material are very excellent, so it is favored by the industry.

In the process of using SAE 1055, attention should be paid to protecting its surface from corrosion, oxidation and other factors, so as not to affect its performance. At the same time, when processing the material, it is also necessary to pay attention to the accuracy and safety of processing technology to ensure the quality of products and the safety of workers.

As one of the important materials in modern industry, SAE 1055 has a very broad application prospect. With the continuous development of industrialization, people's demand for high-quality materials will be increasing. Therefore, the market potential of SAE 1055 is very huge, which deserves our attention and play in the use and promotio

SAE 1055:

1. Chemical composition requirements: carbon (C) content in 0.52%-0.60%, manganese (Mn) content in 0.60%-0.90%.

2. Mechanical properties: tensile strength between 620 MPa and 1030 MPa, yield strength between 350 MPa and 930 MPa, elongation between 10% and 25%.

3. Heat treatment: Steel can be normalized or annealed, and has good processing properties.

Data Table for:Carbon steel:SAE 1055



Steel grade type	Carbon steel:
Standard	SAE
Production specifications	Steel plate,Sheet, Coil,Flat bar,Round bar, Strip steel,wire,All kinds of forgings.
Mchining	Turning Milling Grinding Deep hole drilling: length max 9.8 meters.
Range of work	Round bar steel: 1mm to 2000mm Square-shape steel: 10mm to 1000mm steel Plate/sheet:0.08mm to 800mm Width: 10mm to 1500mm Lenth: We can supply any lenth based on the customer's requirement. Forging: Shafts with flanks/pipes/tubes/slugs/donuts/cubes/other shapes Tubings: OD: φ4-410 mm, with wall thickness ranging from 1-35 mm.
Heat treatment	Normalizing,Annealing,Tempering,Quenching,Hardening and tempering,Seasoning,Surface hardening,Carburizing

Chemical Composition

Element	Content (%)
Iron, Fe	98.41-98.9
Manganese, Mn	0.60-0.90
Carbon, C	0.50-0.60
Sulfur, S	≤ 0.050
Phosphorous, P	≤ 0.040

Physical Properties

Properties	Metric	Imperial
Density	7.85 g/cm3	0.284 lb/in3

Mechanical Properties

Properties	Metric	Imperial
Tensile strength, ultimate	660 MPa	95700 psi
Tensile strength, yield	560 MPa	81200 psi
Modulus of elasticity	190-210 GPa	29700-30458 ksi
Bulk modulus (typical for steel)	140 GPa	20300 ksi
Shear modulus (typical for steel)	80 GPa	11600 ksi
Poissons ratio	0.27-0.30	0.27-0.30
Elongation at break (in 50 mm)	10%	10%
Reduction of area	40%	40%
Hardness, Brinell	197	197
Hardness, Knoop (converted from Brinell hardness)	219	219
Hardness, Rockwell B (converted from Brinell hardness)	92	92
Hardness, Rockwell C (converted from Brinell hardness. Value below normal HRC range, for comparison purposes only)	13	13
Hardness, Vickers (converted from Brinell hardness)	207	207
Machinability (based on AISI 1212 steel. as 100 machinability)	55	55

Thermal Properties

Properties	Metric	Imperial
Thermal expansion co-efficient	11 µm/m°C	6.11 µin/in°F
Thermal conductivity	49.8 W/mK	346 BTU in/hr.ft2.°F

Application Range：
