50CrV4 Spring Steel Bar
50CrV4 spring steel bar is an excellent material for a wide range of applications in the automotive, aerospace, and industrial sectors. This steel bar is highly durable, strong, and resistant to wear and tear, making it an ideal choice for manufacturing parts that can withstand high stress and pressure.
In addition, 50CrV4 spring steel bar offers excellent thermal stability, ensuring it can maintain its strength and stiffness even under extreme conditions. Furthermore, the unique properties of this steel bar make it perfect for use in springs and other mechanical components where resilience and flexibility are key requirements.
By choosing 50CrV4 spring steel bar for your manufacturing needs, you are making a wise and sound investment in the future of your business. With its exceptional strength, durability, and versatility, this steel bar is sure to deliver optimal performance and long-lasting results for years to come.
Moreover, 50CrV4 spring steel bar is a sustainable material that is fully recyclable and environmentally friendly. It meets all the requirements of global standards, making it a perfect choice for manufacturing companies looking to reduce their carbon footprint and contribute to a cleaner, greener earth.
STANDARD SPECIFICATION FOR SPRING STEEL 50CRV4 SHEET PLATE
Specifications : EN 10083 / EN 10083
Sheet : thickness range from .008" to .0125"
Plate : thickness ranges from .0125" to 5.00"
Size : 15NB to 150NB In
Heat Treatment : Forging or hot rolling:Normalising:Soft annealing:Hardening:Tempering:1050 - 850°C 870 - 900°C/air 680 - 720°C/furnace 820 - 860°C/oil 540 - 680°C/air Treated for cold shear ability +S:Soft annealed
Hardness : Annealed, Soft, Hard, Half Hard, Full Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Chemical Composition of 50CrV4 Grade (As Per IS:2507)
- CARBON 0.45 - 0.55 %
- MANGANESE 0.70 - 1.10 %
- SILICON 0.10 - 0.35 %
- SULPHUR 0.03 % MAX
- PHOSPHOROUS 0.035 % MAX
- CHROMIUM 0.90 - 1.20 %
- VANADIUM 0.10 - 0.20 %
SPRING STEEL 50CRV4 SHEET PLATE EQUIVALENT GRADES
| STANDARD | DIN | BS | SAE | IS | EN | JIS | AFNOR | Material No. |
| Spring Steel C55 | 50CV4 | 735A51, 735M50, 735H51 |
6150 | 50Cr4V2 | EN47 | SUP10 | 50CrV4, 51CV4 | 1.8159 |
SPRING STEEL 50CRV4 SHEET PLATE EQUIVALENT GRADES
| STANDARD | DIN | BS | SAE | IS | EN | JIS | AFNOR | Material No. |
| Spring Steel C55 | 50CV4 | 735A51, 735M50, 735H51 |
6150 | 50Cr4V2 | EN47 | SUP10 | 50CrV4, 51CV4 | 1.8159 |
Hot Tags: 50crv4 spring steel bar, China 50crv4 spring steel bar manufacturers, suppliers, factory, Saw Blade Steel, 65Mn Carbon Steel Band Saw Blade, S50c Carbon Steel, Chain Saw Steel, High Carbon Steel Saw Blade, 50CrV4 Spring Alloy Steel Strip
