Carbon Steel Panel S50C
Carbon steel panel S50C is a high-quality and reliable material that is widely used in various industries. It is a popular choice for many applications due to its excellent strength, toughness, and durability properties. With its superior characteristics, this steel panel has become an essential component in the manufacturing of numerous products from automotive parts to machinery.
One of the key benefits of S50C carbon steel panel is its versatility. It can be easily shaped or modified to fit different requirements, making it an ideal choice for many industrial applications. Along with its versatility, it is also an economical material that offers an excellent value for money. It is available in various thicknesses and sizes to cater to different needs.
Moreover, S50C carbon steel panel is corrosion-resistant, making it an excellent choice for outdoor applications. It can withstand harsh weather conditions and extreme temperatures. Additionally, it is highly resistant to wear and tear, ensuring long-lasting performance even in high-demand applications.
Product Specification
Material grade: S50C carbon steel.
- Composition: Carbon content range of 0.47-0.52%, high content, with high strength and hardness, suitable for the production of wear-resistant and high-strength parts.
- Physical properties: the yield strength of 345MPa, the tensile strength is 630MPa, the elongation is 16%, and the hardness is between HBS170-210.
- Chemical properties: The carbon content of carbon steel plate is high, so it has high corrosion resistance and is easy to process, but there is a risk of oxidation in high temperature environment.
- Specifications: can be produced according to customer requirements of a variety of different sizes and thicknesses, usually between 1.5-20 mm thickness, width between 600-2000 mm.
| Comparision of steel grades | |
| DIN | 1C50 |
| AISI | 1050 |
| UNI 7846 | - |
| BS 970 | - |
| UNE 36011 | - |
| SAE J 403-AISI | - |
Chemical Composition of JISG4051 S50C
| Grade | C | Si | Mn | P(%) max | S(%) max | Cr(%) max | Ni(%) max | Cu(%) max |
| S50C | 0.47-0.55 | 0.17-0.37 | 0.50-0.80 | 0.035 | 0.035 | 0.25 | 0.25 | 0.25 |
Mechanical Properties of JISG4051 S50C
|
Tensile Strength σb(MPa)
|
Yield Strength σS(MPa)
|
Elon- Gation Ration δ5 (%) | Reduction of area Psi(%) | Impact merit AKV (J) | Resilient value AKV(J/cm2) | Degree of hardness | Annealed steel | Test Specimen Size (mm) |
| ≥630 | ≥375 | ≥14 | ≥40 | ≥31 | ≥39 | ≤241HB | ≤207HB | 25 |
