Astm Tp316
TP316 is a grade of stainless steel that contains chromium, nickel, and molybdenum. It offers excellent corrosion resistance, high-temperature strength, and good mechanical properties. This grade is commonly used in industries such as chemical processing, oil and gas, food processing, and pharmaceuticals.
The "TP" in ASTM TP316 stands for "Tube, Pipe," indicating that it is specifically for pipes and tubes. The number "316" indicates the composition of the steel, with 316 being a higher grade than 304 stainless steel due to its increased corrosion resistance and higher content of nickel and molybdenum.
Overall, ASTM TP316 is a widely used specification for stainless steel pipes in various industries that require high-temperature and corrosive resistance.
main features of astm tp316
* Superb strength
* Anti corrosive
* Rugged design
* High strength
* Easy to install
* Fine finish
* Durability
* Smooth finish
Our Service
Specifications & Material Grade
|
Standard
|
STM A213,A312,ASTM A269,ASTM A778,ASTM A789
|
|||
|
DIN 17456, DIN17457,DIN 17459
|
||||
|
JIS G3459,JIS G3463
|
||||
|
EN10216, BS3605,GB13296
|
||||
|
Steel Grade
|
300 series
|
|||
|
Material
|
304,304L,309S,310S,316,316Ti,317,317L,321,347,347H,304N,316L, 316N
|
|||
|
Surface
|
Polishing, Annealing, Pickling, Bright
|
|||
|
Wall Thickness
|
0.2-40mm
|
|
|
|
|
Outer Diameter
|
6-200mm
|
|
|
|
|
Technique
|
Hot rolled ,Cold rolled
|
|||
|
Length
|
2m-12m as customers request
|
|||
|
Package
|
Plastic film/Bundles/Wooden case as customers request
|
|||
|
Container Size
|
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM
|
|||
|
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM
|
|
|
||
|
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM
|
||||
|
Out Diameter |
Wall Thickness |
Length |
|
|
Inch |
mm |
mm |
meter |
|
1/2 |
21.3mm |
0.6mm-3.0mm |
0.3m-12m |
|
3/4 |
26.9mm |
0.6mm-3.0mm |
0.3m-12m |
|
1 |
33.4mm |
1.0mm-3.0mm |
0.3m-12m |
|
1-1/4 |
42.3mm |
1.0mm-4.0mm |
0.3m-12m |
|
1-1/2 |
48.3mm |
1.0mm-4.0mm |
0.3m-12m |
|
2 |
60.3mm |
1.5mm-4.0mm |
0.3m-12m |
|
2-1/2 |
76.1mm |
1.5mm-4.0mm |
0.3m-12m |
|
3 |
88.9mm |
1.5mm-9.5mm |
0.3m-12m |
|
4 |
114.3mm |
2.0mm-9.5mm |
0.3m-12m |
|
5 |
141.3mm |
3.0mm-9.5mm |
0.3m-12m |
|
6 |
168.3mm |
3.0mm-12.0mm |
1.0m-12.0m |
|
8 |
219.1mm |
3.2mm-12.0mm |
1.0m-12.0m |
|
10 |
273mm |
3.2mm-12.0mm |
1.0m-12.0m |
|
12 |
323.8mm |
6.0mm-15.0mm |
1.0m-12.0m |
|
14 |
355.6mm |
8.0mm-15.0mm |
1.0m-12.0m |
|
16 |
406.4mm |
8.0mm-20.0mm |
1.0m-12.0m |
Extensive use
1. Chemical Processing: used in the chemical processing industry for handling corrosive chemicals, acids, and solvents. It is used in equipment such as reactors, heat exchangers, tanks, and pipelines.
2. Oil and Gas Industry: commonly used in the oil and gas industry for applications such as offshore platforms, subsea equipment, and pipelines. Its corrosion resistance makes it suitable for handling oil, gas, and other corrosive fluids.
3. Food and Beverage Industry: used in the food and beverage industry for applications such as processing equipment, storage tanks, and piping systems. Its corrosion resistance and hygienic properties make it suitable for use in food and beverage processing.
4. Pharmaceutical Industry: used in the pharmaceutical industry for manufacturing equipment, storage tanks, and piping systems. Its corrosion resistance and ability to withstand high-temperature sterilization processes make it ideal for pharmaceutical applications.
5. Power Generation: used in power generation plants for applications such as steam turbines, boilers, and heat exchangers. Its high-temperature strength and corrosion resistance make it suitable for use in high-pressure and high-temperature environments.
6. Aerospace Industry:used in the aerospace industry for applications such as aircraft engine components, exhaust systems, and fuel lines. Its high-temperature strength and corrosion resistance make it suitable for use in aerospace applications.
Hot Tags: astm tp316, China astm tp316 manufacturers, suppliers, factory, 201 Stainless Steel Pipe, TP 304 Stainless Steel Pipe, 304 Stainless Steel Pipe, Seamless Stainless Steel Pipe, TP 316 Stainless Steel Pipe, Welded Stainless Steel Pipe
