If it is a real 316L stainless steel material, even if it is soaked in seawater for a year, there will not be much corrosion phenomenon, and you can use this piece with confidence.

Send Inquiry

Product Introduction

SS316 316L

For stainless steel, their internal and external corrosion resistance is the same, that is, it will not quickly spread to other places because of a little corrosion on the surface, especially affecting the internal structure, in the household field, 316L stainless steel, the life is still quite long.

connection type:Clamp pressure, ring pressure, groove, socket welding, quick assembly,Welding and threading.

application

Bioengineering
food
pharmaceutical
purified water
electronic engineering
Chemical fiber industry
chemical industry
paper making
beer
high purity gas
Daily chemical products

Equivalent Grades of Stainless Steel Pipes & Tubes in Singapore

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST/KS	AFNOR	EN
SS 304	1.4301	S31600	SUS 304	304S31	08Х18Н10	Z7CN18‐09	X5CrNi18-10
SS 304L	1.4306 / 1.4307	S30403	SUS 304L	3304S11	03Х18Н11	Z3CN18‐10	X2CrNi18-9 / X2CrNi19-11
SS 316	1.4401 / 1.4436	S31600	SUS 316	316S31 / 316S33	–	Z7CND17‐11‐02	X5CrNiMo17-12-2 / X3CrNiMo17-13-3
SS 316L	1.4404 / 1.4435	S31603	SUS 316L	316S11 / 316S13	03Ch17N14M3 / 03Ch17N14M2	Z3CND17‐11‐02 / Z3CND18‐14‐03	X2CrNiMo17-12-2 / X2CrNiMo18-14-3
SS 904L	1.4539	N08904	SUS 904L	904S13	STS 317J5L	Z2 NCDU 25-20	X1NiCrMoCu25-20-5

Chemical Composition of Stainless Steel Pipes & Tubes in Singapore

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N
SS 304	0.08 max	2 max	0.75 max	0.045 max	0.030 max	18 – 20	–	8 – 11	0.10 max
SS 304L	0.035 max	2.0 max	1.0 max	0.045 max	0.03 max	18 – 20	–	8 – 13	–
SS 316	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	11.00 – 14.00	0.10 max
SS 316L	0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	16.00 – 18.00	2.00 – 3.00	10.00 – 14.00	68.89 min
SS 904L	0.020 max	2.00 max	1.00 max	0.040 max	0.030 max	19.00 – 23.00	4.00 – 5.00 max	23.00 – 28.00	–

Mechanical Properties of ASME SA 312 SS Pipes & Tubes in Singapore

Grade	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
SS 304	8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %
SS 316	8.0 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %
SS 904L	7.95 g/cm3	1350 °C (2460 °F)	Psi – 71000 , MPa – 490	Psi – 32000 , MPa – 220	35 %
