304 stainless steel is a common material in stainless steel, with a density of 7.93 g/cm3, also known as 18/8 stainless steel in the industry. High temperature resistance of 800 degrees, with good processing performance, high toughness characteristics, widely used in industrial and furniture decoration industry and food and medical industry.

Send Inquiry

Product Introduction

Is 304 stainless steel seamless pipe different from sandblast pipe?

In fact, the difference between stainless steel surface drawing, frosting and sandblasting is the difference in surface treatment process

The drawing surface of 304 stainless steel pipe is a surface texture formed after grinding with a grinding wheel. Granular feeling will be heavier, characterized by increased friction.

Stainless steel tube frosted surface, in fact, is the original color of stainless steel, the surface is not granular, characterized by: with the longer the use of time, there will be more coated, it will be brighter.

Stainless steel pipe sandblasting surface, is made of fiber interference surface texture in an electrochemical way, the particle sense of the surface is between matte and wire drawing, through electrochemical treatment, can prevent oil, that is to say, such a damaged surface is easier to erase oil.

Stainless steel pipes can still be made into color pipes after the treatment of these surfaces, and the types and styles are different.

Standard	SS 304
WERKSTOFF NR.	1.4301
UNS	S30400
JIS	SUS 304
BS	304S31
GOST	08Х18Н10
AFNOR	Z7CN18‐09
EN	X5CrNi18-10

Chemical Composition Of ASTM A269 TP 304 Stainless Steel Seamless Tubes

SS	304	304N	304LN
Ni	8 – 11	8 – 11	8 – 11
Fe	Balance
Cr	18 – 20	18 – 20	18 – 20
C	0.08 max	0.08 max	0.035 max
Si	0.75 max	0.75 max	0.75 max
Mn	2 max	2 max	2 max
P	0.040 max	0.040 max	0.040 max
S	0.030 max	0.030 max	0.030 max
N		0.10 – 0.16	0.10 – 0.16

Mechanical Properties Of ASTM A269 TP 304 Stainless Steel Seamless Tubes

Density	8.0 g/cm3
Melting Point	1400 °C (2550 °F)
Tensile Strength	Psi – 75000 , MPa – 515
Yield Strength (0.2%Offset)	Psi – 30000 , MPa – 205
Elongation	35 %

ASTM A269 TP 304 Stainless Steel Seamless Tubes Physical Properties

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/⁰C)			Thermal Conductivity (W/m.K)		Specific Heat 0-100⁰C (J/kg.K)	Electrical Resistivity (n.m)
Grade	Density (kg/m3)	Elastic Modulus (GPa)	0-100⁰C	0-315⁰C	0-538⁰C	at 100⁰C	at 500⁰C	Specific Heat 0-100⁰C (J/kg.K)	Electrical Resistivity (n.m)
304/H	8000	193	17.2	17.8	18.4	16.2	21.5	500	720
