316 and 316L stainless steel sheets are materials that offer incredible versatility and performance in a broad range of settings. With their exceptional durability, strength, and resistance to corrosion and other environmental factors, these materials make an excellent choice for anyone looking for reliable and long-lasting solutions.

Send Inquiry

Product Introduction

316 and 316L stainless steel sheet are widely used materials in various industries because of their excellent corrosion resistance, high strength, and durability. These materials are highly versatile and can be used in a variety of applications, including construction, automotive, and aerospace.

The 316L stainless steel sheet is the low carbon version of the popular 316 stainless steel sheet, which is known for its resistance to corrosion in challenging environments such as seawater and acidic solutions. The lower carbon content in 316L stainless steel sheet makes it more weldable and easier to work with, while still maintaining its superior corrosion resistance properties.

Both 316 and 316L stainless steel sheets are highly sought after for their exceptional performance in high-temperature environments, making them ideal for use in applications where heat resistance is crucial. These materials can also withstand exposure to harsh chemicals and acidic solutions, which makes them an ideal choice for use in chemical processing plants and other similar applications.

Product specification

1. Material: made of high quality 316L stainless steel material, with good corrosion resistance and high temperature resistance.

2. Size: common sizes are 1000mm x 2000mm, 1219mm x 2438mm, 1500mm x 6000mm, etc., can be customized according to customer requirements.

3. Surface treatment: surface commonly used treatment methods are polishing and pickling, polished surface is more smooth, suitable for high-end decoration and manufacturing fields; The pickling surface has better corrosion resistance.

4. Application: widely used in chemical industry, paper making, seawater treatment, food processing, medicine, construction and other fields, especially in high temperature and high pressure environment.

5. Special requirements: can be processed into various shapes according to customer requirements, such as round, square, rectangular, hexagonal, etc., and can also be processed into special shapes such as grooves and arches to meet the needs of different fields.

Plate Properties

Grade 316 Plate Properties

GRADE	SHAPE	THICKNESS	SPECIFICATION
316	PLATE	3/16" - 6"	AMS 5507 / ASTM A-240
316L	PLATE	3/16" - 6"	AMS 5524 / ASTM A-240

Chemistry(range or Maximum in %)

GRADE	C	MN	P	S	SI	NI	CR	MO	OTHER
316	0.08	2.00	0.045	0.03	0.75	10.00/14.00	16.00/18.00	2.00	N 0.10 MAX
316L (LOW CARBON)	0.03	2.00	0.045	0.03	0.75	10.00/14.00	16.00/18.00	2.00	N 0.10 MAX
