316 Stainless Steel Sheet Metal
316 stainless steel sheet metal is a reliable and versatile material that is well-suited for a variety of applications. Whether you're working in the aerospace industry, building medical equipment, or constructing industrial machinery, 316 stainless steel sheet metal offers a number of benefits that can help you achieve your goals.
One of the biggest advantages of 316 stainless steel sheet metal is its corrosion resistance. This material is especially resistant to pitting and crevice corrosion, which can be a major problem in many industries. Additionally, it is easy to clean and maintain, which can help you save time and money in the long run.
Another benefit of 316 stainless steel sheet metal is its strength and durability. It is able to withstand high temperatures, pressure, and impact without becoming damaged or deformed. This makes it an excellent choice for applications where strength and resilience are important.
GRADES
316 stainless steel sheet metal is a versatile and highly corrosion-resistant material that is used extensively in many industries. It is an austenitic stainless steel that contains molybdenum, which improves its resistance to corrosion in harsh environments. 316 stainless steel sheet metal comes in different grades, each with unique properties and applications. Below are some of the common grades of 316 stainless steel sheet metal:
1. Grade 316: This is the most common grade of 316 stainless steel sheet metal. It has excellent corrosion resistance, good temperature resistance, and is suitable for use in harsh environments.
2. Grade 316L: This is a low carbon version of grade 316. It has excellent corrosion resistance and is suitable for welding. It is often used in applications where there is exposure to harsh chemicals and high temperatures.
3. Grade 316Ti: This grade has titanium as an alloying element, which improves its stability at high temperatures. It has excellent corrosion resistance and is suitable for use in high-temperature applications.
4. Grade 316N: This grade has nitrogen as an alloying element, which improves its strength and corrosion resistance. It is ideal for use in applications where high strength is required.
5. Grade 316LN: This grade has low carbon, nitrogen, and high molybdenum content, which makes it highly resistant to corrosion in aggressive environments.
COMMON GRADES, SIZES AND SPECIFICATIONS
| Grades | Width | Length | Thickness |
|---|---|---|---|
| 304/304L | Up to 2000mm | Up to 6000mm | From 0.4mm |
| 316/316L | Up to 2000mm | Up to 6000mm | From 0.4mm |
Other stainless steel sheet grades and sizes are available upon request. You can request to cut your stainless steel sheets down to size.
FINISHES
| Finish | Description |
|---|---|
| No. 1 | Rough, dull, uneven appearance. Most suitable for industrial applications. |
| 2B | Dull grey with slight reflective finish. Most commonly used cold rolled mill finish. |
| 4B | Uniform direction brushed look, not highly reflective. An ideal general purpose finish. |
| Bright Annealed (BA) | Cold rolled, annealed in a controlled atmosphere to retain a highly reflective and mirror-like finish. |
| Hairline (HL) | Well-defined directional finish with long and fine lines. |
| No. 8 (Mirror) | Most reflective surface available. Used for cosmetic applications such as mirrors and reflectors. |
|
Mechanical properties of Stainless steel AISI 316 at 20 °C/ 68 °F |
Value |
|
|---|---|---|
|
0.2 % Yield strength Rp 0.2 (N/mm2) |
> 190 N/mm² |
|
|
1.0 % Yield strength Rp 1.0 (N/mm2) |
250 |
|
|
Tensile strength, Rm N/mm2 |
520-670 |
|
|
Elongation at break A5 (%) |
40 / 30 |
lengthwise / crosswise |
|
Notched impact strength ISO-V (J) |
100 J / 60 |
lengthwise / crosswise |
|
Physical properties of Stainless steel AISI 316 |
Value |
|---|---|
|
Density, kg/dm3 |
7.95 |
|
Hardness HB |
< 215 |
|
Is the material magnetic? |
No, not regularly |
|
Is the material polishable? |
Yes, it can be polished very well |
|
Material temperature |
1 % Yield strength of Stainless steel, |
Tensile strength of Stainless steel, |
|---|---|---|
|
100 / 212 °C/°F |
>= 199 / >= 28.9 N / mm² / ksi |
430 / 62.4 N / mm² / ksi |
|
200 / 392 °C/°F |
>= 167 / >= 24.2 N / mm² / ksi |
390 / 56.6 N / mm² / ksi |
|
300 / 572 °C/°F |
>= 145 / >= 21.0 N / mm² / ksi |
380 / 55.1 N / mm² / ksi |
|
400 / 752 °C/°F |
>= 135 / >= 19.6 N / mm² / ksi |
380 / 55.1 N / mm² / ksi |
|
500 / 932 °C/°F |
>= 128 / >= 18.6 N / mm² / ksi |
360 / 52.2 N / mm² / ksi |
|
Chemical composition of Stainless Steel AISI 316 |
C |
Si |
Mn |
P |
S |
Cr |
Mo |
Ni |
|---|---|---|---|---|---|---|---|---|
|
Min % |
16.50 |
2.00 |
10.00 |
|||||
|
Max % |
0.030 |
1.00 |
2.00 |
0.045 |
0.015 |
18.50 |
2.50 |
13.00 |
