ABOUT ALLOY 410
410 SS plate is a high-quality stainless steel plate that is widely used in various industries such as food processing, chemical processing, pharmaceuticals, and many more. It is known for its superior strength, durability, and resistance to corrosion, making it an ideal material for harsh environments.
One of the major advantages of 410 SS plate is its high tensile strength, which makes it resistant to damage even under extreme pressure. This property also makes it an excellent material for applications that require high levels of hardness and toughness. Additionally, this plate is also highly resistant to oxidation and scaling, ensuring that it performs exceptionally well in high temperature environments.
In addition to its physical properties, 410 SS plate is also an attractive option due to its low maintenance requirements. It is relatively easy to clean and can withstand exposure to harsh chemicals without corroding or deteriorating. As such, it requires little upkeep, making it a valuable investment for businesses that prioritize cost-effective solutions.
Overall, 410 SS plate is an excellent material for a wide range of applications and industries. Its superior strength, durability, and resistance to corrosion make it a valuable investment for businesses seeking reliable and long-lasting solutions. And with its low maintenance requirements, it is an affordable and convenient option for many applications.
PROPERTIES
- Density:
- 7.64 g/cm³
- Melting point:
- 1495°C
- Electrical resistivity:
- 5.7x10^-7 Ωm
CHEMICAL ANALYSIS
| % | Cr | Mn | Ni | C | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|
| Min | 11.5 | - | - | 0.08 | - | - | - | - |
| Max | 13.5 | 1 | 0.75 | 0.15 | 1 | 0.04 | 0.03 | Balance |
| PRODUCT FORM | SIZE RANGE FROM | SIZE RANGE TO |
|---|---|---|
| Alloy 410 sheet & plate | 0.5 mm | 152.4 mm |
| Mechanical & Physical Properties | 21°C | 100°C | 500°C | 649°C | 788°C |
|---|---|---|---|---|---|
| Coefficient of Thermal Expansion, µm/m⁰C | - | 9.8 | 11.2 | 11.7 | 11.9 |
| Thermal Conductivity/ kcal/(hr.m.°C) | - | 21.4 | 24.7 | - | - |
| Modulus of Elasticity/ x105 MPa | 2 | - | - | - | - |
| Tensile Strength, ksi | 60-75 |
|---|---|
| 0.2% Yield Strength, ksi | 32-42 |
| Elongation, % | 20-40 |
| Reduction of Area, % | 50-75 |
| Tempering Temperature, °C | - | 149°C | 260°C | 371°C | 566°C | 621°C | 649°C | 704°C | 760°C | 816°C |
|---|---|---|---|---|---|---|---|---|---|---|
| Tensile Strength, ksi | 193.5 | 188.5 | 181.6 | 181.4 | 124.1 | 117.5 | 113 | 101.8 | 96.5 | 131.8 |
| 0.2% Yield Strength | 149.8 | 148.6 | 143.6 | 144.7 | 110.3 | 103.7 | 99.1 | 84.2 | 77.9 | 88.6 |
| Elongation, % | 17 | 17.3 | 16.8 | 16 | 20.8 | 21.3 | 22 | 23.5 | 25 | 19.5 |
| Reduction of Area, % | 56.8 | 59.7 | 61.1 | 61.1 | 67.2 | 66.1 | 66.5 | 68.8 | 69.9 | 59.6 |
| Hardness, Brinell | 388 | 388 | 361 | 361 | 255 | 235 | 229 | 207 | 189 | 257 |
