Abrasion Resistant Steel Plate
The use of Abrasion Resistant Steel Plate has the following advantages:
1. High wear resistance: Abrasion Resistant Steel Plate has very high wear resistance, which can reduce the failure and loss caused by wear of mechanical parts in the process of use.
2. Long life: Because of its high wear resistance, the service life of Abrasion Resistant Steel Plate is relatively long, which can reduce the number of replacement and maintenance costs and improve work efficiency.
3. Focus on energy saving: In the process of using Abrasion Resistant Steel Plate, energy consumption can be reduced, production efficiency can be improved and economic benefits can be achieved.
4. High strength: Abrasion Resistant Steel Plate has high strength, so it can withstand greater pressure and impact force, and better safety performance.
5. Widely used: due to its excellent performance, Abrasion Resistant Steel Plate has been widely used in machinery manufacturing, construction, ships, coal mines and other fields.
In summary, Abrasion Resistant Steel Plate has the advantages of abrasion resistance, long life, energy saving, high strength and wide application, etc., is a very excellent manufacturing material, which provides help for the production and development of all walks of life.
GB T24186 NM360 high strength wear resistant steel plate-chemical composition
| Chemical Composition/% | ||||||||||||
| GRADE | C | Si | Mn | P | S | Cr | Ni | Mo | Ti | Bt* | CEV | ALs |
| Max. | Min. | |||||||||||
| NM360 | 0.25 | 0.7 | 1.6 | 0.025 | 0.015 | 0.8 | 0.5 | 0.5 | 0.05 | 0.0005~0.006 | 0.48 | 0.01 |
| *Bt indicates total boron content | ||||||||||||
GB T24186 NM360 high strength wear resistant steel plate-mechanical properties
| Standard Stipulated Mechanical Property | |||||||
| GRADE | THICK/mm | TENSIBLE STRENGTH Rm MP a | YIELDSTREGNTHA50/% | 一20℃ IMPACT(Lengthway AKv / J | HBW | Deliverystatus | Executive standard |
| NM360 | 3~80 | ≥1100 | ≥12 | ≥24 | 330~390 | Q+T | GB/T24186 |
| If you have special request for the above mechanical properties, please indicate in the contract | |||||||
| Wear-resisting Steel Comparison Table | |||||||
| GB | WISCO | THYSSENKRUPP | DILLINGER | SSAB | JFE | SUMIHARD | NLMK |
| NM300 | ~ | XAR 300 | DILLIDUR 325 L | ~ | ~ | ~ | ~ |
| NM360 | WNM360 | XAR HT | DILLIDUR IMPACT | ~ | JFE-EH360A | K340 | ~ |
| NM400 | WNM400 | XAR 400 | DILLIDUR 400 | HARDOX 400 | JFE-EH400A | K400 | Quard 400 |
| NM450 | WNM450 | XAR 450 | DILLIDUR 450 | HARDOX 450 | JFE-EH450A | K450 | Quard 450 |
| NM500 | WNM500 | XAR 500 | DILLIDUR 500 | HARDOX 500 | JFE-EH500A | K500 | Quard 500 |
| NM550 | WNM550 | XAR 550 | DILLIDUR 550 | HARDOX 550 | ~ | ~ | Quard 550 |
| NM600 | WNM600 | XAR 600 | ~ | ||||
