Made in China
NM360 BHNM400, BHNM450 BHNM500,NR360 NR400, B - HARD360, B - HARD400 (origin: baohua, WuGang, cultivation, baosteel, wisco, laiwu)
What are the thickness specifications of wear-resistant steel plates and common welding wires?
Wear-resistant plates are generally 3+3, 4+2, 5+3, 5+4, 6+4, 6+5, 6+6, 8+4, 8+5, 8+6, 10+5, 10+6, 10+6, 10+8, 10+10, 20+20, etc.
Wear-resistant plate commonly used wire models: LZ570, LZ590, LZ601, LZ606, LZ650, etc. (wire diameter: 2.4-3.2)
The numbers 360,400, 450, 500 indicate the Brinell hardness of the wear plate, the higher the hardness, the higher the yield strength and tensile strength, and the service life is definitely 500.
However, due to the high hardness, the related wear-resistant plate processability has also become worse, such as the bending radius of the wear-resistant plate, and the cost of drilling the wear-resistant plate need to be considered. Choosing the right wear-resistant steel plate is the most important thing, is to pursue longer life or moderate life but easy to process.
NM Steel Chemical composition:
| Steel Grade | Thickness mm |
Grade Level | Chemical Composition Wt% | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| C | Si | Mn | P | S | Mo | Cr | Ni | B | |||
| Max | |||||||||||
| NM 360 | ≤50 | A－E,L | 0.20 | 0.60 | 1.60 | 0.025 | 0.015 | 0.50 | 1.00 | 0.80 | 0.004 |
| 51-100 | A,B | 0.25 | 0.60 | 1.60 | 0.020 | 0.010 | 0.50 | 1.20 | 1.00 | 0.004 | |
| NM 400 | ≤50 | A－E | 0.21 | 0.60 | 1.60 | 0.025 | 0.015 | 0.50 | 1.00 | 0.80 | 0.004 |
| 51-100 | A,B | 0.26 | 0.60 | 1.60 | 0.020 | 0.010 | 0.50 | 1.20 | 1.00 | 0.004 | |
| NM 450 | ≤80 | A－D | 0.26 | 0.70 | 1.60 | 0.025 | 0.015 | 0.50 | 1.50 | 1.00 | 0.004 |
| NM 500 | ≤80 | A－D | 0.30 | 0.70 | 1.60 | 0.025 | 0.015 | 0.50 | 1.50 | 1.00 | 0.004 |
NM 360 Steel Plate Mechanical Property:
| Steel Grade | Thickness mm | Grade level | Hardness HBW | Tensile Strength | Longitudinal impact performance(J) | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Yield Strengtha | Tensile Strengtha | Elongation | Yield Ratio | Room Temp | 0℃ | -20℃ | －40℃ | ||||
| NM 360 | 8 | E | 398-429 | 1010-1120 | 1210-1360 | 13-17 | 0.80-0.86 | 30-56 | |||
| 10 | E | 393-426 | 1000-1160 | 1200-1340 | 14-19 | 0.78-0.86 | 22-43 | ||||
| 12 | L | 370-410 | 1040-1110 | 1290-1350 | 19-21 | 0.81-0.84 | 32-40 | ||||
| 16 | D | 378-417 | 930-1070 | 1210-1330 | 19-24 | 0.75-0.83 | 21-42 | ||||
| 20 | D | 363-412 | 940-1110 | 1190-1330 | 14-26 | 0.73-0.84 | 22-41 | ||||
| 30 | C | 370-410 | 920-1060 | 1170-1330 | 13-18 | 0.72-0.80 | 33-52 | ||||
| 40 | B | 360-398 | 885-1080 | 1190-1320 | 13-16 | 0.72-0.82 | 43-61 | ||||
| 50 | B | 358-390 | 820-1020 | 1120-1180 | 16-20 | 0.77-0.84 | 34-45 | ||||
| 80 | A | 380－430 | 1320-1345 | 1420-1460 | 12-13 | 0.83-0.86 | 35-40 | 30-32 | |||
NM 400 Steel Plate Mechanical Property:
| Steel Grade | Thickness mm | Grade level | Hardness HBW | Tensile Strength | Longitudinal impact performance(J) | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| Yield Strengtha | Tensile Strengtha | Elongation | Yield Ratio | Room Temp | 0℃ | -20℃ | ||||
| NM 400 | 10 | C | 420 | 1140 | 1300 | 14 | 0.88 | 93 | 55 | / |
| 15 | D | 413 | 1100 | 1190 | 18 | 0.92 | 62 | 42 | 28 | |
| 20 | A | 393 | 1190 | 1350 | 18 | 0.88 | 55 | / | / | |
| 30 | D | 416 | 1190 | 1450 | 13 | 0.82 | 43 | 38 | 22 | |
| 35 | A | 398 | 1220 | 1360 | 15 | 0.9 | 67 | / | / | |
| 40 | C | 380 | 1250 | 1320 | 14 | 0.95 | 58 | 55 | / | |
| 50 | B | 401 | 1100 | 1430 | 12 | 0.77 | 46 | 31 | / | |
| 50 | A | 387 | 1120 | 1200 | 12 | 0.93 | 45 | / | / | |
NM 360 NM 400 Steel Plate-Hardness Inspect:
| Steel Grade | Dimension mm |
Hardness according to different section HB | HB | |||||
|---|---|---|---|---|---|---|---|---|
| Upper layer | Upper 1/4 | 1/2 | Down 1/4 | Down side | Average | |||
| NM 360 | 80 | 432 | 383 | 343 | 388 | 423 | 393 | 89 |
| 40 | 406 | 409 | 385 | 398 | 398 | 399 | 24 | |
| NM 400 | 20 | 417 | 420 | 423 | 420 | 420 | 420 | 6 |
| 40 | 415 | 426 | 409 | 415 | 415 | 416 | 11 | |
| 50 | 390 | 388 | 388 | 388 | 393 | 389 | 5 | |
