1.0601 (C60) | 1.1221 (C60E) Material Data Sheet

The following is the material data sheet for 1.0601 (C60) and 1.1221 (C60E). These materials are known for their high strength and resistance to wear and tear, making them ideal for a wide range of industrial applications.

1.0601 (C60) Material Data Sheet:

Chemical Composition:

Carbon: 0.57-0.65%
Manganese: 0.60-0.90%
Silicon: 0.15-0.35%
Phosphorus: max 0.025%
Sulphur: max 0.025%

Mechanical Properties:

Tensile strength: 800-1000 MPa
Yield strength: 685 MPa
Elongation at break: 10-14%
Hardness: 190-230 HB

Applications:

1.0601 (C60) is commonly used in the manufacturing of tools, springs, and other mechanical components. Its high strength and wear resistance make it an ideal choice for parts that experience heavy loads or repetitive stress.

1.1221 (C60E) Material Data Sheet:

Chemical Composition:

Carbon: 0.57-0.65%
Manganese: 0.60-0.90%
Silicon: 0.15-0.35%
Phosphorus: max 0.025%
Sulphur: max 0.025%

Mechanical Properties:

Tensile strength: 800-1000 MPa
Yield strength: 685 MPa
Elongation at break: 10-14%
Hardness: 190-230 HB

Applications:

1.1221 (C60E) is similar to 1.0601 (C60) in that it is commonly used in the manufacturing of tools, springs, and other mechanical components. However, it may be preferred in applications where a higher level of toughness is required.

Overall, both 1.0601 (C60) and 1.1221 (C60E) are excellent choices for industrial applications where strength and durability are essential. They are reliable materials that have been widely used for many years, and continue to offer outstanding performance in a wide range of setting

C60 Carbon Steel Round Bar Chemical Composition

C60 Carbon Steel Round Bar Physical Properties

C60 Carbon Steel Round Bar Mechanical Properties
