Mechanical Properties Of SAE1055 Steel
Basic data:
- Chemical composition: Carbon content is 0.50-0.60%, phosphorus content is 0.04% (highest), sulfur content is 0.05% (highest), manganese content is 0.60-0.90%, silicon content is 0.15-0.35%.
- Physical properties: good strength, toughness and wear resistance. Hardness can be adjusted by heat treatment.
- Machining performance: easy to cut and cold form processing. The hardness and toughness of the material can be controlled by heat treatment.
Send Inquiry
Product Introduction
SAE1055 steel is a high-quality carbon steel that is commonly used in various industrial applications. This steel is known for its excellent mechanical properties that make it a strong and durable material. Here are some of the mechanical properties of SAE1055 steel:
- Tensile strength: The tensile strength is around 630 MPa.
- Yield strength: The yield strength is around 530 MPa.
- Elongation: The elongation is about 10% to 15%.
- Hardness: The hardness of SAE1055 steel can vary based on the heat treatment process used, but typically ranges from 170 to 230 HB.
- Fatigue strength: The fatigue strength of SAE1055 steel is moderate and varies depending on the surface condition and the number of cycles.
- Impact strength: The impact strength of SAE1055 steel is relatively low compared to other grades of steel, making it less suitable for applications that require high impact resistance.
- Ductility: The ductility is moderate, allowing it to be easily formed and shaped into various industrial components.
SAE 1055 Chemical composition and Mechanical properties
C(％): 0.52～0.60
Mn(％): 0.60～0.90
P(％)≤: 0.040
S(％)≤: 0.050
SAE 1055 high carbon structural steel plate has good tensile and yield strength and they are tabulated below.
| Yield Rp0.2 (MPa) |
Tensile Rm (MPa) |
Impact KV/Ku (J) |
Elongation A (%) |
Reduction in cross section on fracture Z (%) |
As-Heat-Treated Condition | Brinell hardness (HBW) |
| 867 (≥) | 835 (≥) | 11 | 22 | 23 | Solution and Aging, Annealing, Ausaging, Q+T,etc | 413 |
