Chemical composition Carbon C: 0.47 ~ 0.55 Silicon Si: ≤0.40 Manganese Mn: 0.70 ~ 1.10 Sulfur S: ≤0.030 P: ≤0.030 Chromium Cr: 0.90 ~ 1.20 Nickel Ni: ≤0.35 Copper Cu: ≤0.25 Vanadium: 0.10 ~ 0.25

Send Inquiry

Product Introduction

What is AISI 6150 Steel 1.8159 51CrV4 Spring Steel?

51CrV4 alloy is a low-alloy spring steel material, mainly containing chromium (Cr), vanadium (V) and other elements. Here is some basic information about 51CrV4 alloy:

Execution Standard: 51CrV4 alloys generally comply with the European Standard (EN) 10089 standard, which specifies the technical delivery conditions for low-alloy spring steel. This standard specifies the chemical composition, mechanical properties and heat treatment requirements of 51CrV4.

weldability

On the positive side, AISI 6150 steel can be welded using most conventional welding methods. These include MIG, TIG, and Stick welding using either carbon dioxide or argon-based shielding gases. Additionally, the steel can be easily heat treated after welding to restore its mechanical properties.

However, there are also some negative aspects to consider when welding AISI 6150 steel. One concern is that the steel can be prone to cracking during the welding process. This is especially true if the steel is welded in a hardened or tempered state. Therefore, it is important to preheat the steel before welding to reduce the risk of cracking.

Another potential issue that can arise when welding AISI 6150 steel is that the weld zone may experience lower toughness than the base material. This can be addressed by selecting a welding procedure that produces a uniform heat distribution, such as using a smaller heat-affected zone or lower welding current.
