● Chemical composition (%) : Carbon C: 0.57 ~ 0.65 Silicon Si: 0.17 ~ 0.37 Manganese Mn: 0.50 ~ 0.80 Sulfur S: ≤0.035 P: ≤0.035 Chromium Cr: ≤0.25 Nickel Ni: ≤0.25 Copper Cu: ≤0.25

Send Inquiry

Product Introduction

EN 1.0601 (C60) is a non-alloy steel that belongs to the category of high carbon steels. It is known for its high strength, toughness and excellent wear resistance properties. This type of steel is commonly used in applications that require reliable and strong components such as gears, shafts, and springs.

One of the key advantages of EN 1.0601 (C60) steel is its ability to withstand high stress and strain without breaking or deforming. This makes it an ideal material for heavy-duty applications that demand durability and rigidity. Additionally, it is easy to machine, which makes it a popular choice in manufacturing and engineering industries.

EN 1.0601 (C60) steel is also known for its excellent wear resistance properties, which makes it suitable for use in high-friction and abrasive environments. It is capable of retaining its strength and shape even when exposed to harsh conditions, making it a highly reliable and robust material for a range of applications.

Moreover, EN 1.0601 (C60) steel is easy to weld, which makes it an ideal choice for fabricators and welders who need a reliable and strong material for their projects. Its versatility and strength make it a popular choice for a range of industrial and commercial applications.

In conclusion, EN 1.0601 (C60) steel is a non-alloy steel that offers excellent strength, toughness, and wear resistance properties. It is highly versatile and easy to work with, making it a popular choice for a variety of industrial and manufacturing applications.

Chemical composition % of steel C60 (1.0601): EN 10277-2-2008

Cr + Mo + Ni = max 0.63

C	Si	Mn	Ni	P	S	Cr	Mo
0.57 - 0.65	max 0.4	0.6 - 0.9	max 0.4	max 0.045	max 0.045	max 0.4	max 0.1

Mechanical properties of steel C60 (1.0601)

Nominal thickness (mm):	to 16	16 - 100	100 - 250	250 - 500	500 - 1000
Rm - Tensile strength (MPa) (+N)	710	670	650	630	620

Nominal thickness (mm):	5 - 10	10 - 16	16 - 40
Rm - Tensile strength (MPa) (+C)	800-1150	780-1130	730-1100

Nominal thickness(mm):	to 16	16 - 100	100 - 250	250 - 500	500 - 1000
Re - Upper yield strength or R_p0.2 - 0.2% proof strength (MPa) (+N)	380	340	310	275	260
