S45C Chemical Composition Standards And Properties
S45C is a medium carbon steel with a chemical composition of:
- Carbon (C): 0.42%-0.50%
- Silicon (Si): 0.15%-0.35%
- Manganese (Mn): 0.60%-0.90%
- Phosphorus (P): 0.030% max
- Sulfur (S): 0.035% max
The properties of S45C include:
- Density: 7.85 g/cm3 (0.284 lb/in3)
- Hardness: Rockwell hardness of 60-66 HRC
- Tensile strength: 570-700 MPa (82-101 ksi)
- Yield strength: 335-405 MPa (48-59 ksi)
- Elongation: 13-25%
- Properties: good mechanical properties, such as high tensile strength, good toughness, and excellent hardenability. It also has good machinability and can be easily welded.
- Applications: used in various industries, such as automotive, machinery, and construction. It is commonly used to manufacture gears, shafts, axles, and other structural parts.
- Quality control: strict quality control measures should be implemented. This can include proper heat treatment, careful selection of raw materials, and thorough testing of the finished product.
- Environmental impact: it is important to consider its environmental impact. Recycling and proper disposal of waste materials should be taken into account to minimize its impact on the environment.
PRODUCT APPLICATION
1045 Steel Grade Equivalent Chart
| Country | USA | Germany/UK/France | JAPAN | ISO |
|---|---|---|---|---|
| Standard | ASTM A29/A29M-05 | EN 10083/2-2006 | JIS G4051-2009 | ISO 683/18-1996 |
| Grades | 1045 | C45(1.0503) | S45C | C45E4 |
1045 Steel Chemical Composition
| STAND | C(%) | Mn(%) | P(%) | S(%) | Si(%) | Cr(%) | Mo(%) | Ni(%) |
|---|---|---|---|---|---|---|---|---|
| ASTM A29/A29M-05 | 0.43-0.50 | 0.60-0.90 | Max 0.040 | Max 0.050 | Max 0.10 | - | - | - |
| EN 10083/2-2006 | 0.42-0.50 | 0.50-0.80 | Max 0.045 | Max 0.045 | Max 0.40 | Max 0.40 | Max 0.10 | Max 0.40 |
| JIS G4051-2009 | 0.42-0.48 | 0.60-0.90 | Max 0.030 | Max 0.035 | 0.15-0.35 | - | - | ≤0.20 |
| ISO 683/18-1996 | 0.42-0.50 | 0.50-0.80 | ≤0.035 | ≤0.035 | 0.10-0.40 | - | - | - |
1045 Steel Physical Properties
| Physical Properties | Metric | Imperial |
|---|---|---|
| Density | 7.87 g/cc | 0.284 lb/in³ |
C45 Steel Mechanical Properties
| Mechanical Properties | Metric | Imperial |
|---|---|---|
| Hardness, Brinell | 163 | 163 |
| Hardness, Knoop (Converted from Brinell hardness) | 184 | 184 |
| Hardness, Rockwell B (Converted from Brinell hardness) | 84 | 84 |
| Hardness, Vickers (Converted from Brinell hardness) | 170 | 170 |
| Tensile Strength, Ultimate | 565 MPa | 81900 psi |
| Tensile Strength, Yield | 310 MPa | 45000 psi |
| Elongation at Break (in 50 mm) | 16.0 % | 16.0 % |
| Reduction of Area | 40.0 % | 40.0 % |
| Modulus of Elasticity (Typical for steel) | 200 GPa | 29000 ksi |
| Bulk Modulus (Typical for steel) | 140 GPa | 20300 ksi |
| Poissons Ratio (Typical For Steel) | 0.290 | 0.290 |
| Shear Modulus (Typical for steel) | 80 GPa | 11600 ksi |
