ALLOY STEEL 50CRV4
Alloy steel 50CRV4 is a strong and durable material that has numerous applications in various industries. This type of steel is made by combining iron with a small percentage of other metals, including chromium, vanadium, and carbon. These metals work together to produce a steel alloy that has high strength, good toughness, and excellent corrosion resistance.
One of the key benefits of 50CRV4 is its high strength-to-weight ratio, which makes it an ideal material for use in structures that must be both strong and lightweight. It is used in the automotive industry to make parts such as springs, suspension systems, and gears, where its strength, durability, and resistance to fatigue are highly valued.
Steel 50CRV4 is also commonly used in construction, either on its own or as part of a composite material. It can be used to make beams, bars, and plates, as well as fasteners and other components that require high strength and toughness. In the energy industry, it is used to make components for power plants and other energy-generating equipment, as well as in oil and gas exploration and production.
In addition to its physical properties, 50CRV4 also has excellent machining and fabrication characteristics, which make it easy to work with and shape into complex parts and components. This means that it can be used in a wide range of applications, from industrial machinery to consumer products.
Steel Material 50CrV4 - Alternative Names List
DIN/EN51CrV4, 51CrMnV4, 50CrV4
BSI/AFNORG 61500
AISI/SAE6150
Designation by Standards
| Brand Name | Ravne No. | Mat. No. | DIN | EN | AISI |
| VCV150 | 732 | 1.8159 | 50CrV4 | 50CrV4 | 6145/6150 |
Chemical Composition (in weight %)
| C | Si | Mn | Cr | Mo | Ni | V | W | Others |
| 0.51 | max. 0.40 | 0.90 | 1.05 | - | - | 0.18 | - | - |
Mechanical Properties in Hardening and Tempering Condition
| Diameter (mm) | 0.2 % proof stress (N/mm2) | Tensile strength (N/mm2) | Elongation (%) | Reduction of area (%) | Notch impact energy (ISO-V) (J) |
| <16 | 900 | 1100-1300 | 9 | 40 | 30 |
| 17-40 | 800 | 1000-1200 | 10 | 45 | 30 |
| 41-100 | 700 | 900-1100 | 12 | 50 | 30 |
| 101-160 | 650 | 850-1000 | 13 | 50 | 30 |
| 161-250 | 600 | 800-950 | 13 | 50 | 30 |
