2205 Sheet
2205 plate is a kind of high strength, high corrosion resistance steel plate. It has excellent mechanical properties and chemical stability, and is one of the most suitable materials for a variety of harsh environments.
This material is very suitable for chemical, Marine, oil, gas and other fields because of its high corrosion resistance. It is believed that in the future, this material will be more and more widely used in industrial production, so that many production areas have been further innovation and development.
Not only that, all kinds of high-tech fields will also increase the demand for 2205 plates. Its high strength makes it have high application value in manufacturing devices and tools, ships, etc., and provides solid support for all kinds of high-tech products.
Specifications
- Dimensions: Width from 1 to 2 meters, length from 3 to 6 meters.
- Thickness: 0.3mm to 30mm.
- Surface: bright surface, mirror surface, frosted surface, etc.
- Material: 2205 stainless steel material.
Chemical Composition:
| Cr | Ni | Mo | Co | Nb (+Ta) | Ti | V | W | Cu | C | Mn | N | Si | P | S | Fe | Al | |
| Min | 22.00 | 4.50 | 3.00 | 0.14 | 0.20 | ||||||||||||
| Max | 23.00 | 6.50 | 3.50 | 0.03 | 0.20 | 0.70 | 0.03 | 0.02 | Bal |
Mechanical Properties:
| 0.2% Proof Stress | 450 N/mm2 | 65ksi |
| Tensile Strength | 655 N/mm2 | 95ksi |
| Elongation, 5.65√S0 | 25% | |
| Reduction of area | 45% | |
| Hardness (Brinell) | <270 | |
| Impact Strength (Room Temp) | 80J (av) | |
| Impact Strength (-46°C) : Longitudinal | <100mm 80J | |
| 100-260mm 45J (35J min) | ||
| >260mm For info only | ||
| Impact Strength (-46oC) : Transverse | 50-260mm 45J (35J min) | |
| >260mm For info only | ||
Notes:
1. 2205 stainless steel sheet is a versatile stainless steel material that is commonly used in various industrial applications due to its excellent properties such as high strength, corrosion resistance, and durability.
2. The material is made up of a combination of chromium, nickel, molybdenum, and nitrogen, which gives it superior resistance to pitting, crevice corrosion, and general corrosion in aggressive environments.
3. The sheet is available in various thicknesses, sizes, and finishes, making it suitable for a wide range of applications, including marine, chemical processing, oil and gas, and food processing industries.
4. The high strength of super duplex plate makes it ideal for structural applications, where it can provide significant weight savings compared to other types of materials.
5. The sheet is also known for its excellent weldability, which allows for easy fabrication and repair of components.
6. In addition, duplex steel plate is environmentally friendly as it is fully recyclable and has a long service life, making it a sustainable choice for many industries.
7. Due to its many advantages, duplex 2205 plate suppliers is a popular choice among manufacturers, designers, and engineers who require high-performance materials for their products or projects.
8. Overall, 2205 duplex plate is an excellent choice for those seeking a durable, high-strength, and corrosion-resistant material that can meet the demands of a wide range of industrial applications.
Physical Properties:
| Density (Kg/m3) | 7810 |
| Magnetic Permeability (20°C) | <50 |
| Young’s Modulus (kN/mm2) | 190 |
| Specific Electrical Resistance, 20°C (µΩ.m) | 0.85 |
| Mean coefficient of thermal expansion, 20-300°C (m/m/oC) | 11 x 10-6 |
| Specific Heat, 20°C (J/kg.K) | 400 |
| Thermal conductivity, 20°C (W/m.K) | 15 |
Applications:
- Process industry components in sulphuric acid, nitric acid, phosphoric acid, ethylene oxide, polypropylene & PVC production
- Equipment handling organic & fatty acids, chemical storage, tankers, heat exchangers
- Marine industry and shipbuilding propellers, shafts, rudders, shaft seals, pumps, bolts, fasteners, valves, instrumentation
- Oil and chemical tankers
- Oil & Gas industry pumps, valves, pipe, vessels, wellhead equipment, subsea equipment, separators, heat exchangers
- Pollution control systems, effluent scrubbing, flue gas desulphurisation (FGD)
- Waste water treatment, sour water purification
- Pulp & paper industry applications such as pulp liquor heaters, bleach tower linings, digesters, brownstock washers
- Food industry applications including brewery piping, evaporators, hot liquor tanks, presses
