NM500 Execution standard: GB/T 24186-2009
Class classification :NM500ANM500B
Heat treatment: tempering (quenching + tempering).
Tensile direction: transverse
Tensile strength: ≥1250(1650)
Elongation A50% : ≥8

Send Inquiry

Product Introduction

AR500, also known as NM500, is a type of abrasion-resistant steel plate that is designed to withstand both heavy wear and impact. This type of steel plate is commonly used in the mining, construction, and manufacturing industries, where heavy equipment is constantly subjected to harsh conditions.

AR500 steel is made up of high-quality, hardened metals that are specifically engineered to provide maximum abrasion resistance. The steel is alloyed with chromium and other materials to help prevent wear and corrosion, while still remaining lightweight and flexible enough for use in a variety of applications.

The unique properties of AR500 steel make it an ideal choice for applications that require high durability and toughness. It is often used in components and structures that are subjected to heavy impact and wear, such as bulldozer blades, conveyor liners, and cutting edges for mining equipment.

Overall, AR500 steel is a highly versatile and reliable choice for any application that requires excellent wear and impact resistance. Its exceptional hardness, toughness, and strength make it an ideal material for a wide range of applications.

NM	RAEX	Creusabro	XRA	DILLIDUR	Durostat	Hardox
NM500	RAEX500	Creusabro8000	XAR 500	500V	Durostat 500	Hardox500

Abrasion Resistant Steel Plate NM500 Chemical Composition
Heat No.	Grade	C	Si	Mn	P	S	Ni+Mo+Cr	others	CEQ
S21301389	NM500	0.29	0.31	0.99	0.011	0.003	＜2.5	micro	0.71
S11301559	NM500	0.28	0.32	0.97	0.003	0.003	＜2.5	micro	0.71

Abrasion Resistant Steel Plate NM500 Mechanical Properties
Standard		Grade	Thick. / mm	Rm / MPa		A50/ %	Impact T/ ℃	KV2 / J	Hardness /HBW
GB/T 24186-2009		NM500	≤80	≥1200		≥10	--20	≥24	470~530
Plate No.	Heat No.	Grade	Thick. / mm	Re / MPa	Rm / MPa	A50/ %	Impact T/ ℃	KV2 / J	Hardness /HBW
T3111011010	S21300161	NM500	21	1355	1665	9.5	-20	47/53/46	499
Q3331271010	S21300160	NM500	51	1573	1665	13.5	-20	42/44/56	499
