The chemical composition of NM300 is as follows: Carbon (C) : 0.26-0.32% Silicon (Si) : 0.20-0.40% Manganese (Mn) : 1.20-1.50% Phosphorus (P) : ≤0.025% Sulfur (S) : ≤0.010% Chromium (Cr) : ≤0.30% Nickel (Ni) : ≤0.30% Copper (Cu) : ≤0.30% Vanadium (V) : ≤0.10% Boron (B) : ≤0.005%

Send Inquiry

Product Introduction

The nearest equivalent grade for NM300 steel would be AR 300 steel. AR 300 is a wear-resistant steel with a hardness of approximately 300 HB. Other equivalent grades may include Hardox 300, Abrazo 300, Roq-tuf AM 300, and Dillimax 300.

Metal sheets made from NM300 steel or its equivalent grades are commonly used in applications that require high wear resistance, such as mining, construction, and agriculture equipment. These sheets are also used in the manufacturing of heavy-duty machinery parts, buckets, liners, and blades.

Metal sheets made from NM300 steel or its equivalent grades have high tensile strength, good toughness, and excellent weldability, making them ideal for use in harsh environments and high-stress applications. They offer exceptional durability and long service life, reducing downtime and maintenance costs.

Product specification

1. Features and uses: For the grade of nm300 steel, it is a high-strength and low-alloy hot-rolled steel plate. It has good mechanical properties, especially in terms of high strength and wear resistance. Therefore, it is usually used in the manufacture of various structures and mechanical equipment, such as excavators, road rollers, forklifts, etc.

2. Material index: The chemical composition of nm300 steel includes carbon, silicon, manganese, phosphorus, sulfur, chromium and other elements, the specific indicators are as follows:

Carbon (C)%: 0.25-0.35

Silicon (Si)%: 0.15-0.40

Manganese (Mn)%: 1.00-1.50

Phosphorus (P)%: ≤0.030

Sulfur (S)%: ≤0.030

Chromium (Cr)%: 1.20-2.00

In addition, the mechanical properties of nm300 steel requirements are as follows:

Yield strength (MPa): ≥295

Tensile strength (MPa): 570-720

Elongation (%): ≥20

Impact strength (J): -20℃≥27

Hardness (HB): 280-320

3. Equivalent materials: There are many equivalent materials for nm300 steel, such as Q345B steel in China, A572 Grade 60 steel in the United States, and SM490A steel in Japan. These steels are similar to nm300 steel in terms of mechanical properties and chemical composition and can therefore be used as their equivalent materials.

4. Production standards: There are many production standards for nm300 steel, such as GB/T 24186-2009 standard in China, JIS G3106-2008 standard in Japan, ASTM A572 standard in the United States, etc. These standards specify the requirements of the chemical composition, mechanical properties and production process of the steel to ensure its quality stability and reliability.
