Wear Resistant Steel Plates Nm360
Super wear-resistant steel plate grades are: WNM450A, WNM450B, WNM450C, WNM500A, WNM500B, WNM500C.
High toughness wear-resistant steel plate: WNM360D, WNM360E, WNM400D, WNM400E.
Weldability high wear-resistant steel plate: WNM360L.
Wear Resistant Steel Plates Nm360
The wear-resistant layer of the alloy is mainly chromium alloy, and other alloy components such as manganese, molybdenum, niobium and nickel are also added. The carbides in the metallographic structure are distributed like fibers, and the fiber direction is perpendicular to the surface. Carbide microhardness can reach more than HV1700-2000, surface hardness can reach HRC58-62. Alloy carbides have strong stability at high temperatures, maintain high hardness, and also have good oxidation resistance, and are completely normal for use within 500℃.
The wear layer has narrow channel (2.5-3.5mm), wide channel (8-12mm), curve (S, W), etc. It is mainly chromium alloy, and other alloy components such as manganese, molybdenum, niobium, nickel and boron are added. The carbides in the metallographic structure are distributed like fibers, and the fiber direction is perpendicular to the surface. Carbide content 40-60%, microhardness can reach more than HV1700, surface hardness can reach HRC58-62.
Specifications:
| Standard Grade | DIN : XAR300, XAR400, XAR450, XAR500, XAR600, X120Mn12; 1.3401, etc... SSAB : WELDOX700, WELDOX900, WELDOX960, etc. NF : FORA400, FORA500; Creusabro4800, Creusabro8000, etc. EN : QUARD400, QUARD450, QUARD500; RAEX320, RAEX400, RAEX500, etc. JIS : WEL-HARD400, WEL-HARD500,etc. GB : NM360, NM400, NM450, NM500, NM550, NM600, etc. |
| Thickness | 2-300mm(2-100mm usually used) |
| Width | 1000-3000mm(1000-2200mm usually used) |
| Length | 1000-12000mm as your request |
| Surface | clean, finishing, blasting and painting according to your request |
| Delivery State | hot-rolled, controlled rolling, normalizing, annealing, tempering, quenching, N+T, Q+T, and other delivery states as your request |
Customized service We can cut according to the size or drawing required by the customer. What's more, we can provide painting on the surface of the board to better protect it.
We also provide special packaging such as wooden boxes.
Application
