304 stainless steel plate Features:
corrosion resistance
high temperature resistance
high strength
beautiful and other advantages

Send Inquiry

Product Introduction

SS 304 stainless steel coil is a grade of stainless steel that contains 18% chromium and 8% nickel, which makes it resistant to corrosion and oxidation. It is commonly used in applications where high strength and resistance to corrosion are required, such as in food processing equipment, chemical processing plants, and medical equipment. The coil is available in a variety of sizes and thicknesses, and can be supplied in both cold-rolled and hot-rolled conditions. It is also available in a variety of finishes, including brushed, polished, and satin.

Thickness range: 0.02mm to 4.0mm.
Width range: 10mm to 2000mm.
Length range: can be customized according to customer requirements.
Surface treatment: 2B, BA, HL, mirror, etc.
Application: Ss 304 stainless steel coil is widely used in construction, chemical, pharmaceutical and other fields, such as making boilers, pressure vessels, chemical vessels and so on.

Chemical Composition
The typical chemical composition is shown in the table below.
Grade	Standard	304 Chemical Composition
		C	Si	Mn	Cr	Ni	P	S	Mo	Others
		≤ %	≤ %	%	%	%	≤ %	≤ %	≤ %	%
304	ASTM A240	0.08	0.75	2	18.0 - 20.0	8.0 - 10.5	0.045	0.03	-	N≤ 0.10
1.4301	EN 10088-2	0.07	1	2	17.0 - 19.5	8.0 - 10.5	0.045	0.015	-	N≤ 0.11
SUS304	JIS G 4304 \| JIS G 4305	0.08	1	2	18.0 - 20.0	8.0 - 10.5	0.045	0.03	-	-

Mechanical Properties
The mechanical properties are given in the table below.
Grade	Standard	304 Mechanical Properties
		Tensile Strength	Yield Strength 0.2%	Elongation >%	Hardness
		(MPa) ≥	(MPa) ≥	Elongation >%	HRB ≤	HB ≤
304	ASTM A240	515	205	40	92	201
1.4301	EN 10088-2	520	210	45	90	215
SUS304	JIS G 4304 JIS G 4305	520	205	40	90	187

304 stainless steel is a common material in stainless steel, with a density of 7.93 g/cm3, which is also called 18/8 stainless steel in the industry.

High temperature resistant to 800°C and processability. Common labeling methods on the market include 0Cr18Ni9 and SUS304. Among them, 0Cr18Ni9 generally means national standard production, and 304 generally means ASTM standard production.
