Wear Resistant Steel Sheet Plate X120Mn12 Mn13
Thickness: 3mm-200mm
Width: 1000mm-3000mm
Length: 2000mm-12000mm
Surface treatment: hot rolling and cold rolling
Tensile strength: ≥685MPa
Yield strength: ≥430MPa
Elongation: ≥35%
Hardness: HB240-320
Wear resistant steel sheet plate X120Mn12 Mn13 is a high-strength and abrasion-resistant steel plate that is widely used in various industries such as mining, construction, and transportation. This steel plate has excellent wear resistance, toughness, and impact resistance, making it a popular choice for high-stress and harsh environments.
Here are some specifications of Wear resistant steel sheet plate X120Mn12 Mn13:
1. Thickness: 3mm-80mm
2. Width: 1000mm-3200mm
3. Length: 1000mm-12000mm
4. Hardness: HB220-320
When it comes to Wear resistant steel sheet plate X120Mn12 Mn13, it is important to note that this steel plate is widely appreciated for its high tensile strength and excellent abrasion resistance. It is also heat-treated, which further enhances its hardness and toughness.
| Item | wear resistant MN13 10MM steel plate hot rolled alloy steel sheet plate |
| Length | 4-12m |
| Width | 1000mm - 2500mm |
| Thickness | 4mm-100mm |
| Tolerance | Standard tolerance |
| Standard | GB,AISI,ASTM,JIS,DIN,API |
| Technical | Hot rolled |
| Application | Used for bridge and construction riveting, bolted and welded structure, as well as general purpose structural steel quality of carbon steel, steel plate and bar steel. |
| Packing | 1.In bundles 2.Standard export packing 3.According to customer's requirements. |
| Delivery detail | Normally 7-10 working days after get deposits or according to quantity |
Chemical composition (%)
|
Brand |
C |
Si |
Mn |
P |
S |
|
Mn13 |
0.90-1.20 |
0.30-0.80 |
11.00-14.00 |
≤0.035 |
≤0.030 |
Mechanical properties
|
Tensile Strength |
Elongation |
20°C Impact Resistance |
Initial Hardness(HB) |
Hardness after Hardened(HB) |
180°old Bending Test |
|
≥900MPa |
≥40% |
ak≥50(J) |
190-250 |
≥300 |
Qualified |
Quality Inspection
Mechanical Properties
Application：
